2 Layer Rogers 4350B Electronic Video Amplifiers Double Side Circuit Design
2 Layer Rogers 4350B Electronic Video Amplifiers Double Side Circuit Design
Specifications
Brand Name :
XCE
Model Number :
XCEM
Certification :
CE,ROHS, FCC,ISO9008,SGS,UL
Place of Origin :
China
MOQ :
1pcs
Price :
negotiation
Payment Terms :
T/T,Western union
Supply Ability :
1, 000, 000 PCS / week
Delivery Time :
5-10 days
Packaging Details :
inner: vacuum-packed bubble bag outer: carton box
Material :
Rogers4350
Layer :
2
Min line space :
5mil
Min line width :
5mil
Copper thickness :
1OZ
Board size :
188*188MM
Panel :
1
Description

Rogers4350B Electronic Video Amplifiers Circuit Design

Customize RO4350B Board are UL 94V-0 rated for active devices and high power RF designs

Cellular Base Station Antennas and Power Amplifiers

Microwave point to point (P2P) links

Automotive Radar and Sensors

RF Identification (RFID) Tags

LNB’s for Direct Broadcast Satellites

Key specifications/special features:

Rogers PCB

Rogers 4350B, Roger3003, Rogers4003,Roger 5880,Rogers6002 and more material on stock

PCB thickness: 0.2-2mm+/-10%

Final copper: 0.5-10oz

Min hole: 0.2mm

Min line width/space: 4/4mil

Min hole copper: 20μm/25μm

Solder mask: green/blue/red/black/gray/white

Legend: white/black/yellow

Surface: OSP/HAL lead-free/immersion gold/immersion tin/

immersion silver/flash gold/hard gold

Outline: rout and score/V-cut

E-test: 100%

Certificates: UL, SGS, RoHS Directive-compliant, ISO

Files: Gerber Protel DXP Auto CAD PADs eagle

Testing: flying probe test, E-test, X-ray Inspection, AOI

Customize Rogers4350B Board Design

Capabilities

Custom and Commercial Communication Systems

Complete Wireless System Architecture and Design

Miniature RF Design

Baseband Design

Wireless Firmware

Concept to Production

High and Low Volumes

CUSTOMIZING FOR YOU

RF Design

Rogers4350B Board

Custom Integrated Microwave Assemblies

Microwave Motion Sensor Board

Sensor Module Rogers PCB Board

Bridge Tester Board

RF module Board

Applications: Radar/EW/Science/Telecom

QUALITY GUARANTEED

Labview control software and GUI for instrument control and test routines

ISO 9001:2008 certification

UNE.EN 9100 certification

Application of MIL standards as needed

Application of ECSS standards as needed

Airborne / space / ground equipment

Hi-Rel design and manufacturing procedures

Our customers have the right to:

?Receive the exact item ordered or an acceptable alternative;

?Receive within the highest standards the exact quantity ordered;

?Be charged the agreed price;

?Receive the goods exactly when expected;

?Receive the goods in an acceptable condition;

?Receive timely and accurate documentation;

?Receive prompt response to all enquiries; and

?Be treated with courtesy and respect, with the highest ethics and integrity

Capability of Rogers 4350 circuit board

Rigid PCB Capability
No. Item Capability
1 Layer Count 1-30Layers
2 HDI Type 1+N+1, 2+N+2
3 Material Teflon,Rogers,Taconic,Isola,F4B etc
4 Board thickness 0.2~5.0mm
5 Board Size Max 600*1000mm (24"x40")
Min 30x50mm
6 Copper Thickness Outer layer 1oz~6oz
Inner layer 0.5oz~5oz
7 Min. Line Width/Space 4/4mil(0.1/0.1mm)
8 Finished Hole size Mechanical 0.20~6.30mm
Laser 5mil, 6mil
9 Blind/buried via(Mechanical) 0.2mm (min)
10 Aspect Ratio 10:1
11 Hole Dia.Tolerance PTH ±0.075mm(3mil)
NPTH ±0.05mm (2mil)
12 Hole Position Tolerance ±0.05mm (2mil)
13 Bow & Twist ≤0.75%
14 Peel strength 1.4N/mm
15 Thermal stress 288 degrees centigrade & 20 Sec
16 Test Voltage 50-300V
17 Soldermask color Green, Red, Blue, Black, White,Yellow
18 Outline Tolerance ±0.10mm (4mil)
19 Surface Finish HASL, Lead free HASL, Immersion Gold/Tin/Silver, OSP, Flash Gold, Gold fingers, Plating Hard Gold, Carbon lnk, Peelable mask


Product tags

hdmi distribution amplifier 1x4

,

vga amplifier

,

tv horizontal output transistor
