Description

Electrical Design/RF&Wireless Design RF Amplifiers, Waveguide Detectors, Waveguide Couplers, High Power Amplifiers

Key specifications/special features:
Rogers PCB
Rogers 4350B, Roger3003, Rogers4003,Roger 5880 and more material on stock
PCB thickness: 0.2-2mm+/-10%
Final copper: 0.5-10oz
Min hole: 0.2mm
Min line width/space: 4/4mil
Min hole copper: 20μm/25μm
Solder mask: green/blue/red/black/gray/white
Legend: white/black/yellow
Surface: OSP/HAL lead-free/immersion gold/immersion tin/
immersion silver/flash gold/hard gold
Outline: rout and score/V-cut
E-test: 100%
Certificates: UL, SGS, RoHS Directive-compliant, ISO
Files: Gerber Protel DXP Auto CAD PADs eagle
Testing: flying probe test, E-test, X-ray Inspection, AOI

Application:
High Power Amplifier, TMA, TMB, LNA: for GSM, UMTS, 3G, PCS, PCN, WCDMA, TD-SCDMA, EDGE, CDMA2000
Repeater
Phase Shifter
Antenna
Filters and Coupler
Passive Components

Advantage:
Exceptional Interlaminar Bond
Low Moisture Absorption
Enhanced Dimensional Stability
Low Z-Axis Expansion
Stable Dk Over Frequency
Circuit Miniturization
Increased Flexural Strength

Advantage:
Specialized in high frequency PCB, double-sided multi-layer PCB manufacturer,
maximum processing layers 28 layers, the company has a full range of domestic and imported
high frequency material(Rogers ROGERS, TACONIC series, high frequency microwave PTFE circuit
boards, Teflon Teflon, PTFE circuit boards, dielectric constant ranging from 2.2 10.6), to provide quality
and efficient products for you


Sufficient stock:
We have sufficient rogers material raw as follow:RO4003C,RO4350B,RO4360,RO4533,RO4535,RO4730,
RO4232,RO4233,RO3003,RO3006,RO3010,RO3035,RO3203,RO3206,
RO3210,RO3730,RO5780,RO5880,RO6002,RO3202,RO6006,
Frequently-used is 4003C,4350B,5880
So we can do pcb circuit board with your detail requirements in the case of you send us gerber files or any other files
