Open / sealed Thin Section Deep Groove Ball Bearings Single Row ,6800 Series
Open / sealed Thin Section Deep Groove Ball Bearings Single Row ,6800 Series
Open / sealed Thin Section Deep Groove Ball Bearings Single Row ,6800 Series
Open / sealed Thin Section Deep Groove Ball Bearings Single Row ,6800 Series
Open / sealed Thin Section Deep Groove Ball Bearings Single Row ,6800 Series
Open / sealed Thin Section Deep Groove Ball Bearings Single Row ,6800 Series
Open / sealed Thin Section Deep Groove Ball Bearings Single Row ,6800 Series
Open / sealed Thin Section Deep Groove Ball Bearings Single Row ,6800 Series
Open / sealed Thin Section Deep Groove Ball Bearings Single Row ,6800 Series
Open / sealed Thin Section Deep Groove Ball Bearings Single Row ,6800 Series
Open / sealed Thin Section Deep Groove Ball Bearings Single Row ,6800 Series
Open / sealed Thin Section Deep Groove Ball Bearings Single Row ,6800 Series
Specifications
Brand Name :
NSK / NTN / FAG / NACHI / KOYO / FSK / OEM
Model Number :
6828
Certification :
ISO9001-2000 / CE / ROHS / UL
Place of Origin :
JAPAN
MOQ :
1 pcs
Price :
Talk in the letter
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
100000pcs/month
Delivery Time :
5-7Days After Details Confirmed
Packaging Details :
1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Model No. :
6828
Size :
140 × 175× 18mm
Weight :
0.84kg
Seal :
2RS / ZZ / Open
Part Name :
China Deep Groove Ball Bearing
Character :
Thin Wall
Description

Open / sealed 6800 Series Thin Section Ball Bearings Single Row C3

Bearing Specification :

Bearing Model No.

6828

Bearing Name:

Deep Groove Ball Bearing

Bearing Size:

140 × 175× 18mm

Bearing Weight:

0.84kg

Seal:

2RS / ZZ / Open

Bearing Drawing :

Open / sealed Thin Section Deep Groove Ball Bearings Single Row ,6800 Series

Bearings Detailed Pictures :

Open / sealed Thin Section Deep Groove Ball Bearings Single Row ,6800 Series

Open / sealed Thin Section Deep Groove Ball Bearings Single Row ,6800 Series

Open / sealed Thin Section Deep Groove Ball Bearings Single Row ,6800 Series

Thin-Wall Deep Groove Ball Bearing List:

Bearing No. Size(mm) Seal Type Mass(kg)
Open Steel Shield
d D B r
(min)
6828 140 175 18 1.1 6828 - - 0.84
6928 140 190 24 1.5 6928 - - 1.9
16028 140 210 22 1.1 16028 - - 2.86
6028 140 210 33 2 6028 6028Z 6028ZZ 4.15
6228 140 250 42 3 6228 6228Z 6228ZZ 7.47
6328 140 300 62 4 6328 6328Z 6328ZZ 21.8
6830 150 190 20 1.1 6830 - - 1.2
6930 150 210 28 2 6930 - - 2.64
16030 150 225 24 1.1 16030 - - 3.58
6030 150 225 35 2.1 6030 6030Z 6030ZZ 4.48
6230 150 270 45 3 6230 6230Z 6230ZZ 9.41
6330 150 320 65 4 6330 - - 26.2
6832 160 200 20 1.1 6832 - - 1.3
6932 160 220 28 2 6932 - - 3.01
6032 160 240 38 2.1 6032 - - 5.89
6232 160 290 48 3 6232 6232Z 6232ZZ 14.3
6332 160 340 68 4 6332 - - 28.6
6834 170 215 22 1.1 6834 - - 1.85
6934 170 230 28 2 6934 - - 3.17
6034 170 260 42 2.1 6034 - - 7.92
6234 170 310 52 4 6234 - - 17.5
6334 170 360 72 4 6334 - - 34
6836 180 225 22 1.1 6836 - - 2.02
6936 180 250 33 2 6936 - - 4.68
6036 180 280 46 2.1 6036 - - 10.3
6236 180 320 52 4 6236 - - 18.3
6336 180 380 75 4 6336 - - 41.9
6838 190 240 24 1.5 6838 - - 2.6
6938 190 260 33 2 6938 - - 4.9
6038 190 290 46 2.1 6038 - - 10.8
6238 190 340 55 4 6238 - - 23
6338 190 400 78 5 6338 - - 48.2
6840 200 250 24 1.5 6840 - - 2.7


Our Deep Groove Ball Bearings:

Deep groove ball bearings 6828

miniature thin-wall bearings,and different types of low noise,non-standard and special bearings.
(1) bearing bore diameter:3mm-50mm
(2) Bearing range:
60series bearing:606,607.608,6000,6001,6002,6003,6004,6005,6006,6007,6008,6009, 6010,6012,6013,6014,6015
62series bearing :626,627,628,629,6200,6201,6202,6203,6204,6205,6206,6207,6208,6209,6210,
6211,6212
63series bearing:6300,6301,6302,6303,6304,6305,6306,6307,6308,6309,6310,6311,6312 67series bearing:6705
68series bearing:686,687,688,689,6800,6801,6802,6803,6804,6805,6806,6807,6808,6809,6810 69series bearing:696,697,698,699,6900,6901,6902,6903,6904,6905,6906,6907,6908,6909,6910 16000series bearing:16001,16002,16003,16005,16007
(3) bearing Sealing form:OPEN,RS,2RS,Z,ZZ,RZ,2RZ,N,NR
(4) bearing Material:Gcr15
(5) Quality standard: ISO9001:2000
(6) Chief uses:automatic transmission mechanisms, home appliance motors, motorcycles, power tools, sports goods, office applianceal

Our Bearing Production Range:
1. Tapered Roller Bearing
2. Deep Groove Ball Bearing

3. Truck Wheel Bearing

4. Automobile Wheel Bearing

5. Cement Mixer Bearing

6. Clutch Release Bearing

7. Self Aligning Ball Bearing
8. Cylindrical Roller Bearing
9. Needle Bearing
10. Angular Contact Bearing
11. Thrust Ball Bearing
12. Thrust Roller Bearing
13. Pillow Block Bearing
14. Spherical Roller Bearing

About Our Factory :

Open / sealed Thin Section Deep Groove Ball Bearings Single Row ,6800 Series

Open / sealed 6800 Series Thin Section Ball Bearings Single Row C3 , Get Cheap Price from China Deep Groove Ball Bearing Factory Now !
