UCT Series Pillow Block Ball Bearings for Textile Machinery , Metric
UCT Series Pillow Block Ball Bearings for Textile Machinery , Metric
UCT Series Pillow Block Ball Bearings for Textile Machinery , Metric
UCT Series Pillow Block Ball Bearings for Textile Machinery , Metric
UCT Series Pillow Block Ball Bearings for Textile Machinery , Metric
UCT Series Pillow Block Ball Bearings for Textile Machinery , Metric
UCT Series Pillow Block Ball Bearings for Textile Machinery , Metric
UCT Series Pillow Block Ball Bearings for Textile Machinery , Metric
UCT Series Pillow Block Ball Bearings for Textile Machinery , Metric
UCT Series Pillow Block Ball Bearings for Textile Machinery , Metric
Specifications
Brand Name :
FSK / TR / ASAHI / FYH / NSK / NTN / OEM
Model Number :
UCT208
Certification :
ISO9001-2000 / ROHS / UL / CE
Place of Origin :
CHINA
MOQ :
1 pcs-10pcs
Price :
0.1USD-10USD
Payment Terms :
30% Deposit , Balance After BL Copy
Supply Ability :
100000pcs/month
Delivery Time :
3-7Days After Deposit
Packaging Details :
1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) PLASTIC TUBE PACKING / KRAFT PACKING
Model No. :
UCT208
Size :
40mm × 49.2mm × 146mm
Weight :
2.43kg
Standard :
ISO9001:2008
Type :
Pillow Block
Clearance :
oil, grease, dry
Description

UCT Series Pillow Block Ball Bearings for Textile Machinery , Metric


FSK Pillow Block Bearings :

Pillow block bearing is a kind of bearing that looks like a small ball bearing that has a casting pedestal or a pressed steel plate and a double seal. If you will look closely inside it, you will see that the pillow block bearings is very much the same as the other kinds of bearing like the deep groove ball bearings. The only difference is that is you will look closely at the outer ring of the pillow block bearings, you can see that it has section balls which is best use with the concave part of the bearing pedestal.
Pillow blocks are usually mounted in cleaner environments & generally are meant for lesser loads of general industry. These differ from "plummer blocks" which are bearing housings supplied without any bearings & are usually meant for higher load ratings & corrosive industrial environments. However the terms pillow-block & plummer-block are used interchangeably in certain parts of the world

UCT Pillow Block Bearings Drawing :

UCT Series Pillow Block Ball Bearings for Textile Machinery , Metric

Pillow Bloack Bearings with Housing List :

Bearing Unit Shaft Dia Dimensions(mm) Weight
No. d (kg)
mm o g s p q b k e
UCT202 15 16 10 51 32 19 51 12 76 0.78
UCT203 17 16 10 51 32 19 51 12 76 0.77
UCT 204 20 16 10 51 32 19 51 12 76 0.81
UCT205 25 16 10 51 32 19 51 12 76 0.92
UCT206 30 16 10 56 37 22 57 12 89 1.01
UCT207 35 16 13 64 37 22 64 12 89 1.7
UCT208 40 19 16 83 49 29 83 16 102 2.43
UCT209 45 19 16 83 49 29 83 16 102 2.58
UCT210 50 19 16 83 49 29 86 16 102 2.78
UCT211 55 25 19 102 64 35 95 22 130 4.17
UCT212 60 32 19 102 64 35 102 22 130 4.9
UCT213 65 32 21 111 70 41 121 26 151 7.3
UCT214 70 32 21 111 70 41 121 26 151 7.36
UCT215 75 32 21 111 70 41 121 26 151 7.99
UCT216 80 32 21 111 70 41 121 26 165 8.92
UCT217 85 38 29 124 73 48 157 30 173 11.46
UCT218 90 40 30 130 80 48 140 30 190 14.76

Bearing Specification :

Model Number

UCT208

Part Name

Pillow Block Ball Bearing

Brand

FSK / TR / ASAHI / FYH / NSK / NTN / OEM

Precision Rating

P6 / P4 / P5
Material Bearing: Chrome Steel , Housing: Casting / Forging
Cage Steel Cage

Dimensions(mm)(d*D*b)

40mm × 49.2mm × 146mm

Weight / Mass ( KG )

2.43kg

HS Code

8482800000
Original Country Show CHINA

Bearings Detailed Pictures :

UCT Series Pillow Block Ball Bearings for Textile Machinery , Metric

UCT Series Pillow Block Ball Bearings for Textile Machinery , Metric

FSK Payment and Shipping

FSK Bearing Advantage
1. Good raw material and promised working life 1 years or 30,000 kilometers
2. 100% finished product check before shipment
3. ISO9001/TS16949 quality control system
4. 24 hours aftersale service
5. Short production time and fast delivery
6. More than 100 different items and small orders can be accepted
Material
Hydraulic clutch bearing use high quality bearing steel Gcr15 for rings and imported steel for balls.
Payment Terms

We accept L/C,D/P,D/A,T/T,Westunion,Paypal all payment types if you have enough good credit.

We have credit insurace company as partner.
Packing Information

Plastic Bag +Single Box Packing + Paper Carton + Poly Wooden Pallet / Neutral packing / Customer's

packing
Why choose FSK Bearing
We supply Hydraulic clutch bearing with low noise, long working life application and high quality.

UCT Series Pillow Block Ball Bearings for Textile Machinery , Metric​ , Get Cheap Price from China Bearing Factory Now !
