UCT213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing
UCT213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing
UCT213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing
UCT213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing
UCT213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing
UCT213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing
UCT213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing
UCT213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing
UCT213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing
UCT213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing
Specifications
Brand Name :
ASAHI / FYH / NSK / NTN / FSK / OEM
Model Number :
UCT213
Certification :
ISO9001-2000 / SGS / UL / CE / IAF
Place of Origin :
CHINA
MOQ :
1 pcs-5pcs
Price :
0.01-20USD
Payment Terms :
30% Deposit , Balance After BL Copy
Supply Ability :
100000pcs/month
Delivery Time :
3-7Days After Deposit
Packaging Details :
1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) PLASTIC TUBE PACKING / KRAFT PACKING
Model No. :
UCT213
Size :
65mm × 167mm × 224mm
Weight :
7.3kg
Hardness :
58-62HRC
Service :
OEM is acceptable
Use feature :
High temperature/tough Environment
Description

Uct213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing

Bearing Specification :

Model Number UCT213
Part Name Pillow Block Ball Bearing
Brand ASAHI / FYH / NSK / NTN / FSK / OEM
Precision Rating P6 / P4 / P5
Material Bearing: Chrome Steel , Housing: Casting / Forging
Cage Steel Cage
Dimensions(mm)(d*D*b) 65mm × 167mm × 224mm
Weight / Mass ( KG ) 7.3kg
HS Code 8482800000
Original Country Show CHINA


FSK Pillow Block Bearings :

Types:

UC, UEL, UK, SA, SB, SER, UCP, UCF, UCFL, UCT, UCFC, UCPH, UCPA, UCHA, UCFB, UCFA, UCC, UCLP, UCLF, UCFD, UCPP, UCPF, UCPFL, UCPFT, UCBLF, UCTH, UCTL, UCTU ETC..
Material: Chrome Steel, Carbon Steel, Stainless Steel, Plastic, Ceramic
Precision: ABEC-1, ABEC-2, ABEC-3, ABEC-5, ABEC-7, ABEC-9, ABEC-11.
Application: Conveyors, Mining applications, Pulp and paper mills, Rolling mills ETC.
Service: 1. We can change the color according to your actual requirements.
2. Customized the marks based on your requirements.
3. Choose the different package to your needs.

UCT Pillow Block Bearings Drawing :

UCT213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing

Pillow Bloack Bearings with Housing List :

Bearing Unit Shaft Dia Dimensions(mm) Weight
No. d (kg)
mm o g s p q b k e
UCT202 15 16 10 51 32 19 51 12 76 0.78
UCT203 17 16 10 51 32 19 51 12 76 0.77
UCT 204 20 16 10 51 32 19 51 12 76 0.81
UCT205 25 16 10 51 32 19 51 12 76 0.92
UCT206 30 16 10 56 37 22 57 12 89 1.01
UCT207 35 16 13 64 37 22 64 12 89 1.7
UCT208 40 19 16 83 49 29 83 16 102 2.43
UCT209 45 19 16 83 49 29 83 16 102 2.58
UCT210 50 19 16 83 49 29 86 16 102 2.78
UCT211 55 25 19 102 64 35 95 22 130 4.17
UCT212 60 32 19 102 64 35 102 22 130 4.9
UCT213 65 32 21 111 70 41 121 26 151 7.3
UCT214 70 32 21 111 70 41 121 26 151 7.36
UCT215 75 32 21 111 70 41 121 26 151 7.99
UCT216 80 32 21 111 70 41 121 26 165 8.92
UCT217 85 38 29 124 73 48 157 30 173 11.46
UCT218 90 40 30 130 80 48 140 30 190 14.76

Bearings Detailed Pictures :

UCT213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing

UCT213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing

UCT213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing

FSK Bearing Advantage and Service

Pre-sales:
1. OEM &ODM service
2. We promise to reply your inquiry in 24 hours.
3. Complete product information will be offered
4. Free sample will be sent if you need .
5. Any other reasonable requirements as per requested
During production ,we provide:
1. Schedule of production
2 .Mass production picture will offered
3. Any other reasonable requirements as per requested
Finish production:
1. Courier tracking number
2. Documents you need
3. Customer satisfy survey
4. Any other resasonable requirements as per requested

Uct213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing, Get Cheap Price from China Bearing Factory Now !

Contact With Us Freely :

UCT213 Adjustable Bearings Pillow Block Unit With Cast Iron Housing
