LM10 UU Linear Bearings 10mm × 19mm × 29mm Ball Bushing
LM10 UU Linear Bearings 10mm × 19mm × 29mm Ball Bushing
LM10 UU Linear Bearings 10mm × 19mm × 29mm Ball Bushing
LM10 UU Linear Bearings 10mm × 19mm × 29mm Ball Bushing
LM10 UU Linear Bearings 10mm × 19mm × 29mm Ball Bushing
LM10 UU Linear Bearings 10mm × 19mm × 29mm Ball Bushing
LM10 UU Linear Bearings 10mm × 19mm × 29mm Ball Bushing
LM10 UU Linear Bearings 10mm × 19mm × 29mm Ball Bushing
LM10 UU Linear Bearings 10mm × 19mm × 29mm Ball Bushing
LM10 UU Linear Bearings 10mm × 19mm × 29mm Ball Bushing
LM10 UU Linear Bearings 10mm × 19mm × 29mm Ball Bushing
LM10 UU Linear Bearings 10mm × 19mm × 29mm Ball Bushing
Specifications
Brand Name :
NSK / NTN / KOYO / NACHI / FSK
Model Number :
LM10 UU
Certification :
ISO9001-2000 / CE / ROHS / UL
Place of Origin :
CHINA
MOQ :
1 pcs
Price :
Talk in the letter
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
100000pcs/month
Delivery Time :
5-7Days After Details Confirmed
Packaging Details :
1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Material :
Gcr15 Chrome Steel
Dimension :
10mm × 19mm × 29mm
Part Name :
ball bushing / shaft guiding
HS Code :
8482990000
Number of Row :
Four
Precision Rating :
P0, P3, P4, P5 ,P6
Description

Lm10 UU Linear Bearings 10mm × 19mm × 29mm Ball Bushing

Bearing Specification :

Model Number

LM10 UU

Part Name

Linear Motion Bearing
Structure Linear Ball Bearings

Brand

NSK / NTN / KOYO / KBE / FSK

Material

Gcr15 Chrome Steel

Precision Rating

P0 P6 P5 P4 P2
Cage Steel Cage / Nylon Cage / Light Alloy Cage
Dimension 10mm × 19mm × 29mm
HS Code 8482990000
Original Country Show CHINA

Contact Person

Ms. Ellie Liao
Skype fskbearing1
Mail fsk_bearing@yahoo.com

Description:

LM linear bearing: LM3UU,LM4UU,LM5UU,LM6UU,LM8UU,LM8S,LM10UU,LM12UU,LM13UU,LM16UU,LM20UU,LM25UU,LM30UU,LM35UU,LM40UU,LM50UU,LM60UU, LM80UU,LM100UU

LM10 UU Linear Bearings 10mm × 19mm × 29mm Ball BushingLM10 UU Linear Bearings 10mm × 19mm × 29mm Ball Bushing

Other Models We Can Offer

Model No. Main dimensions Basic load rating
Inscribed bore diameter Outer diameter Length Dynamic rating Static rating Mass
dr D L C C0
mm mm mm N N G
LM 3 3 7 10 88.2 108 1.4
LM 4 4 8 12 88.2 127 1.9
LM 5 5 10 15 167 206 4
LM 6 6 12 19 206 265 8
LM 8S 8 15 17 176 225 11
LM 8 8 15 24 265 402 16
LM 10 10 19 29 373 549 30
LM 12 12 21 30 412 598 31.5
LM 13 13 23 32 510 775 43
LM 16 16 28 37 775 1180 69
LM 20 20 32 42 863 1370 87
LM 25 25 40 59 980 1570 220
LM 30 30 45 64 1570 2750 250
LM 35 35 52 70 1670 3140 390
LM 40 40 60 80 2160 4020 585
LM 50 50 80 100 3820 7940 1580


Bearings Detailed Pictures :

LM10 UU Linear Bearings 10mm × 19mm × 29mm Ball Bushing

LM10 UU Linear Motion Bearings 10mm × 19mm × 29mm Ball Bushing, Get Cheap Price from China Steering Bearing Factory Now !

Contact With Us Freely

Wuxi FSK Transmission Bearing Co., Ltd
Address: No. 900 North Jie Fang Road
Chongan District Wuxi Jiangsu China
Contact : Ellie Liao

Mobile: 86-13621509768
Mail: fsk_bearing@yahoo.com
Skype: fskbearing1
QQ: 3305008190
