Nonstand 28BCS15 Motorcycle Crankshaft Bearing 28mm × 72mm × 18mm
Nonstand 28BCS15 Motorcycle Crankshaft Bearing 28mm × 72mm × 18mm
Nonstand 28BCS15 Motorcycle Crankshaft Bearing 28mm × 72mm × 18mm
Nonstand 28BCS15 Motorcycle Crankshaft Bearing 28mm × 72mm × 18mm
Nonstand 28BCS15 Motorcycle Crankshaft Bearing 28mm × 72mm × 18mm
Nonstand 28BCS15 Motorcycle Crankshaft Bearing 28mm × 72mm × 18mm
Nonstand 28BCS15 Motorcycle Crankshaft Bearing 28mm × 72mm × 18mm
Nonstand 28BCS15 Motorcycle Crankshaft Bearing 28mm × 72mm × 18mm
Specifications
Brand Name :
FSK / NKK / NTN / IKO / Any brand you want
Model Number :
8BCS15
Certification :
ISO9001-2000 / CE / ROHS / UL / SGS
Place of Origin :
CHINA
MOQ :
1 pcs
Price :
Talk in the letter
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
100000pcs/month
Delivery Time :
5-7Days After Details Confirmed
Packaging Details :
1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Model No. :
8BCS15
Size :
28mm × 72mm × 18mm
Weight :
0.35kg
Material :
Chrome Steel / Stainless Steel
Seal Model :
28BCS15NSL2
Row :
Single Row
Description

Nonstand 28BCS15 Deep Groove Ball Bearing Motorcycle Crankshaft Bearing

28BCS15 Bearing Summarize

Product information
Name: Inched deep groove ball bearings
Brand: FSK
Item no: 28 bcs15 TM - SC06842 K1/63/28
Material: GCR15
Deep Groove Ball bearing is one of the most common type in rolling bearing.Basic deep groove ball bearing consists of an outer ring, an inner ring, a set of steel ball and a group of cage, deep groove ball bearing type code is 6. Imperial deep groove ball bearing is the dimensions and tolerances in imperial units said deep groove ball bearings

28BCS15 Bearing Specification :

Model Number

8BCS15

Part Name

Inched Deep Groove Ball Bearing

Brand

FSK / NKK / NTN / IKO / Any brand you want
Material Gcr15 Chrome Steel

Dimensions(mm)(d*D*b)

28mm × 72mm × 18mm

Weight / Mass ( KG )

0.35kg

HS Code

8482102000

Original Country Show

 CHINA

Bearings Detailed Pictures :

Nonstand 28BCS15 Motorcycle Crankshaft Bearing 28mm × 72mm × 18mm

Nonstand 28BCS15 Motorcycle Crankshaft Bearing 28mm × 72mm × 18mm

Nonstand 28BCS15 Motorcycle Crankshaft Bearing 28mm × 72mm × 18mm

Nonstandard Deep Groove Ball Bearings Catalog

Bearing NO. Size Load Rating Weight
d D B C Cr Cor Kg
RLS4 12.7 33.338 9.525 8.525 4.36 2.51 0.038
RLS5 15.875 39.688 11.112 11.112 8.62 4.51 0.067
RLS6 19.05 47.625 14.288 14.288 9.08 6.2 0.12
RLS7 22.225 50.8 14.288 14.288 8.72 5.19 0.142
RLS8 25.4 57.15 15.875 15.875 10.78 6.98 0.19
RLS9 28.575 63.5 15.875 15.875 12.8 8.4 0.185
RLS10 31.75 69.85 17.463 17.463 27 15.19 0.285
RLS11 34.925 76.2 17.463 17.463 27.4 15.3 0.362
RLS12 38.1 82.55 19.05 19.05 24.32 17.1 0.402
RLS13 41.275 88.9 19.05 19.05 34 19.5 0.522
RLS14 44.45 95.25 20.64 20.64 34 19.5 0.64
RLS16 50.8 101.6 20.64 20.64 42.3 28 0.94
RLS18 57.15 114.3 22.225 22.225 51 35 0.942
RLS20 63.5 127 23.81 23.81 59 42.5 1.12
RLS22 69.85 133.4 23.81 23.81 59 42.5 1.374
RMS4 12.7 41.275 15.875 15.875 8.62 4.51 0.107
RMS5 15.875 46.04 15.875 15.875 9 5.1 0.117
RMS6 19.05 50.8 17.463 17.463 9.08 6.2 0.16
RMS7 22.225 57.15 17.463 17.463 14 7.9 0.23
RMS8 25.4 63.5 19.05 19.05 22 11 0.31
RMS9 28.575 71.44 20.64 20.64 26.7 15 0.375
RMS10 31.75 79.37 22.225 22.225 26.7 15 0.54
RMS11 34.925 88.9 22.225 22.225 25.7 15.3 0.613
RMS12 38.1 95.25 23.81 23.81 38 22 0.786
RMS13 41.275 101.6 23.81 23.81 49 28 0.867
RMS14 44.45 108 26.99 26.99 58 34 0.96
RMS16 50.8 114.3 26.99 26.99 58 34 1.2
RMS18 57.15 127 31.75 31.75 69 48 1.643
RMS20 63.5 139.7 31.75 31.75 87 54.5 2.03
013311371A 22 68 18 18 29.41 15.68 0.55
28BCS15 28 72 18 18 25.7 15.19 0.31
TM-SC06842 28 72 18 18 25.7 15.19 0.31
B30-118 30 72 26 16 25.7 15.19 0.453
30TM11 30 75 21 21 25.7 15.19 0.45
614593 30 65 21 21 19.5 11.3 0.27
32TM03 32 80 23 23 33.5 19.1 0.56
35BCV05Z 35 55 11 10 10.08 5.8 0.12
TM-SC0788N 35 80 24 24 33.5 19.1 0.55
60/22 22 44 12 12 8.1 3.9 0.192
62/22 22 50 14 14 11.6 6.96 0.121
63/22 22 56 16 16 12.46 7.36 0.176
60/28 28 52 12 12 12.46 7.36 0.102
62/28 28 58 16 16 16.6 8.99 0.172
63/28 28 68 18 18 17.6 8.99 0.28
60/32 32 58 13 13 15.03 9.18 0.133
62/32 32 65 17 17 14.97 10.04 0.228
63/32 32 75 20 20 16.56 10.2 0.472
98205 25 52 12 12 10.78 6.98 0.12
98305 25 62 12 12 12.81 8.4 0.16
98305B 25 62 12 12 23.5 10.84 0.18
19341 25 62 14 14 16.56 9.6 0.175
6006D 30 59 24 24 13.2 8.3 0.3
6006Q 30 62 10 10 15.03 91.8 0.135
30B60 30 62 10 10 11.73 8.38 0.26
12BC04S3 12 42 10 10 7.64 3.72 0.07
440146C 16 42 13 13 9.4 5 0.12
B18Z-B1 18.72 38 10 10 6.4 3.7 0.04
