Small Size Full Complement Cylindrical Roller Bearings For Machine Shaft
Small Size Full Complement Cylindrical Roller Bearings For Machine Shaft
Small Size Full Complement Cylindrical Roller Bearings For Machine Shaft
Small Size Full Complement Cylindrical Roller Bearings For Machine Shaft
Small Size Full Complement Cylindrical Roller Bearings For Machine Shaft
Small Size Full Complement Cylindrical Roller Bearings For Machine Shaft
Small Size Full Complement Cylindrical Roller Bearings For Machine Shaft
Small Size Full Complement Cylindrical Roller Bearings For Machine Shaft
Small Size Full Complement Cylindrical Roller Bearings For Machine Shaft
Small Size Full Complement Cylindrical Roller Bearings For Machine Shaft
Specifications
Brand Name :
FSK / FAG / TIMKE / NTN / NSK / KOYO / OEM
Model Number :
NN3009KP4
Certification :
ISO9001-2000 / CE / ROHS / UL
Place of Origin :
CHINA
MOQ :
1 pcs
Price :
Let's Chat in Detail
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
10000pcs/day
Delivery Time :
3 Days After Details Confirmed
Packaging Details :
1.Industrial packaging: plastic bag + kraft paper + carton + plywood pallets; plastic tube + carton + plywood pallets; 2. Commercial packing: 1pc/plastic bag + color box + carton + plywood pallets 3. As the clients' requirement
Model No. :
NN3009KP4
Size :
45 × 75 × 23mm
Weight :
0.4kg
Cage :
Brass Cage / Steel Cage
Advantage :
Low vocie,high speed, long life
Character :
Short Roller
Description

Small Size Full Complement Cylindrical Roller Bearings For Machine Shaft

Cylindrical Roller Bearings Description

N design The inner ring has two integral flanges and NU design The outer ring of bearings of the NU design has two integral flanges and the inner ring is without flanges. Axial displacement of the shaft with respect to the housing can be accommodated in both directions within the bearing itself.
NJ design The outer ring has two integral flanges and the inner ring one integral flange. The bearings are therefore suitable for the axial location of a shaft in one direction.
NF design The outer ring has one integral flange and the inner ring two integral flanges.
NP design The outer ring has one integral flange and one non-integral flange in the form of a loose flange ring and the inner ring two integral flanges.
NUP design The outer ring has two integral flanges and the inner ring one integral flange and one non-integral flange in the form of a loose flange ring. The bearings can be used as locating bearings, i.e. they can provide axial location for a shaft in both directions.
RN design No outer ring and the inner ring two integral flanges.

Bearing Specification :

Model Number

NN3009KP4

Part Name

Cylindrical Roller Bearings

Brand

FSK / FAG / TIMKE / NTN / NSK / KOYO / OEM

Precision Rating

ABEC-1 to ABEC-9
Vibration and Noise Z0V0 / Z1V1 / Z2V2 / Z3V3
Material Gcr15 Chrome Steel
Number of Row Double Row
Cage Brass Cage / Steel Cage

Dimensions(mm)(d*D*b)

45 × 75 × 23mm

Weight / Mass ( KG )

0.4kg

HS Code

8482800000
Original Country Show CHINA

Bearings Detailed Pictures :

Small Size Full Complement Cylindrical Roller Bearings For Machine Shaft

Part of Thrust Cylindrical Roller Bearings List:

Bearing No. ID mm OD mm Width mm Mass kg
NN3005 NN3005K 25 47 16 0.127
NN3006 NN3006K 30 55 19 0.198
NN3007 NN3007K 35 62 20 0.258
NN3008 NN3008K 40 68 21 0.309
NN3009 NN3009K 45 75 23 0.0407
NN3010 NN3010K 50 80 23 0.436
NN3011 NN3011K 55 90 26 0.647
NN3012 NN3012K 60 95 26 0.693
NN3013 NN3013K 65 100 26 0.741
NN3014 NN3014K 70 110 30 1.06
NN3015 NN3015K 75 115 30 1.11
NN3016 NN3016K 80 125 34 1.54
NN3017 NN3017K 85 130 34 1.63
NN3018 NN3018K 90 140 37 2.09
NN3019 NN3019K 95 145 37 2.19
NN3020 NN3020K 100 150 37 2.28
NN3021 NN3021K 105 160 41 2.88
NN3022 NN3022K 110 170 45 3.71
NN3024 NN3024K 120 180 46 4.04
NN3026 NN3026K 130 220 52 5.88
NN3028 NN3028K 140 210 53 6.34
NN3030 NN3030K 150 225 56 7.77
NN3032 NN3032K 160 240 60 9.41
NN3034 NN3034K 170 260 67 12.8
NN3036 NN3036K 180 280 74 16.8
NN3038 NN3038K 190 290 75 17.8
NN3040 NN3040K 200 310 82 22.7
NN3044 NN3044K 220 340 90 29.6
NN3048 NN3048K 240 360 92 32.7
NN3052 NN3052K 260 400 104 47.7
NN3056 NN3056K 280 420 106 51.1
NN3060 NN3060K 300 460 118 70.7
NN3064 NN3064K 320 480 121 76.6

Brass Cage NN3009KP4 Bearing Small Size for Machine Shaft​​​ ​, Get Cheap Price from China Roller Bearing Factory Now !
