Wearproof Torrington Needle Bearings Catalog For Printing Machine
Wearproof Torrington Needle Bearings Catalog For Printing Machine
Wearproof Torrington Needle Bearings Catalog For Printing Machine
Wearproof Torrington Needle Bearings Catalog For Printing Machine
Wearproof Torrington Needle Bearings Catalog For Printing Machine
Wearproof Torrington Needle Bearings Catalog For Printing Machine
Wearproof Torrington Needle Bearings Catalog For Printing Machine
Wearproof Torrington Needle Bearings Catalog For Printing Machine
Wearproof Torrington Needle Bearings Catalog For Printing Machine
Wearproof Torrington Needle Bearings Catalog For Printing Machine
Specifications
Brand Name :
IKO / INA / FAG / NSK / NTN / FSK / OEM
Model Number :
NA4902
Certification :
ISO9001-2000 / SGS / BV / CE
Place of Origin :
CHINA
MOQ :
1 pcs-5pcs
Price :
0.1-20USD
Payment Terms :
30% Deposit , Balance After BL Copy
Supply Ability :
100000pcs/month
Delivery Time :
3-7Days After Deposit
Packaging Details :
1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) PLASTIC TUBE PACKING / KRAFT PACKING
Model No. :
NA4902
Size :
15mm × 28mm × 13mm
Weight :
0.034kg
Quality :
ABEC1 ABEC3 ABEC5 ABEC7 ABEC9
Row :
Double Row
Vibration :
V4, V3, V2, V1
Description

Wearproof Torrington Needle Bearings Catalog for Printing Machine

Needle Roller Bearings Description :

1. Drawn Cup Needle Bearing

HK Seires
HK0408TN HK1212 BK1210
HK0509 HK1312 BK1212
HK0608 HK1412 HK08X14X10
HK0609 BK1312 HK08X14X12
HK0708 BK0408TN HK10X16X10
HK0709 BK0509 HK10X16X12
HK0808 BK0609 HK12X18X12
HK0810 BK0709 HK10X16X15
HK0910 BK0808 HK12X17X12
HK0912 BK0810 HK12X17X15
HK1010 BK0910 HK12X17X18
HK1012 BK0912 BK12X18X12
HK1015 BK1010 HK12X19X12
HK1210 BK1012

2. Needle Bearing with Inner Ring

NA Series
NA4822A NA4844A/YA4 NA4903AS2
NA4824 NA4852A NA4904A
NA4824A NA4856A NA4904A/YA2
NA4826A NA4900A NA4904
NA4826 NA4900A/YA NA49/22
NA4828A NA4900 NA4905A
NA4828 NA4901A NA4505
NA4832A NA4901 NA49/28
KA4832A NA4902 NA4906A
NA4836A NA4903A NA4906
NA4844A NA4903 NA49/32

3. Needle Bearing without Inner Ring

RNA Series
RNA49/8A RNA4904A RNA4908A
RNA49/9A RNA4905A RNA4909A
RNA4900A RNA4906A RNA4909AF1
RNA4901A RNA4907A RNA4910A
RNA4902A RNA4907A/AS4 RNA4910A/YB2
RNA4902AF RNA4907AF1 RNA4911A
RNA4903A

4.Radial Needle Roller and Cage Assemblie

K Series
K15x19x8 K7x10x8TN K14x18x10/YA5
K16x20x8H K7x10x8TNA K15x19x10
K18x22x8 K8x11x8 K16x20x10
K5x8x8TN K8x11x8TN K17x21x10
K6x9x8 K10x13x8 K17x21x10TV
K6x9x8/SO K14x18x10 K18x22x10
K7x10x8

Needle Roller Bearings List :

Shaft

Diameter

 Bearing Designation Mass BoundaryDimensions BasicLoad Rating

Limiting

Speed
CurrentCode OriginalCode Approx Dynamic Static
mm g mm N rpm
5 NA495 7 5 13 10 2670 2350 34000
NA495TN 7 5 13 10 2670 2350 34000
6 NA496 9 6 15 10 3150 3000 32000
7 NA497 12 7 17 10 3600 3650 30000
8 NKI8/16 8 14 25 16 12400 11300 21500
NA498 16 8 19 11 4300 3950 28000
9 NKI9/12 16.6 9 12 19 12 6200 7000 21700
NA499 17 9 20 11 4850 4900 26000
NKI9/16 21.9 9 19 16
10 NKI10/16 27.3 10 14 22 16 9800 10500 19650
NA4900 4524900 21 10 14 22 13 8000 9000 23700
NA6900 6534900 38.4 10 14 22 22 9000 11000 23700
12 NA4901 4524901 25.1 12 16 24 13 9000 10800 20000
NKI12/20 39 12 16 24 20 14000 18400 21000
NA6901 6534901 44.5 12 16 24 22 6000 21600 20000
NKIS12 58 12 18 30 16 16000 17000 20000
NA12X32X15V 12 32 15
15 NKI15/16 38 15 19 27 16 8800 12800 19100
NKI15/20 45.7 15 19 27 20 12300 19000 19100
NA4902 4924902 32 15 20 28 13 6400 9000 18000
NA6902 6534902 61.6 15 20 28 23 13100 20900 18000
NKIS15 90 15 22 35 20 23500 24000 17000
NA5902 52 15 20 28 18
NAI53212 15 32 12
74802 74802 15 36 25.4
16 NKIS16 16 28 16 13000 17400 22000
NA16X36X24 16 36 24
17 NKI17/16 41.1 17 21 29 16 13000 18200 20000
NA4903 4544903 32.8 17 22 30 13 7000 10000 17000
NA6903 6534903 68.2 17 22 30 23 14400 24900 17000
NA5903 56 17 22 30 18 15200 21700 18000
NA17 17 37 20

Details about FSK Needle Roller Bearings:

Needle roller bearings NK,NKS,RNA49,RNA69,RNAO,NKI,NKIS,NA49,
NA69,NAV,RNAV,RNA49..RS,RNA49..2RS
Radial needle roller and K,KZK,KNL,K..ZW,KBK
cage assemblies
Drawn cup needle roller bearing HK,BK,HK..2RS,MFY,SCE,BCE,BK..RS,F,HK..RS,MF,FY
Inner ring IR,LR
Yoke type track rollers RSTO,RNA22..2RSX,NATV,STO,NA22..2RS,
NATV..PP,STO..X,NA22..2RSX,NUTR,RNA22..2RS,
NATR,NUTR.X
Curve rollers KR,KRV,KRVE..PP,KR..PP,KRV..PP,NUKR,
KRE..PP,KRVE,NUKRE
Combined radial thrust bearings NKIA,NKX,NKX..Z,NKIB,NKXR,NKXR..Z,NX,NX..Z
One way clutch HF,HFL
Axial bearings AXK,AXW

NA Series Needle Roller Bearings Drawing :

Wearproof Torrington Needle Bearings Catalog For Printing Machine
Bearing Specification :

Model Number

NA4902

Part Name

Needle Roller Bearing

Brand

IKO / INA / FAG / NSK / NTN / FSK / OEM

Precision Rating

ABEC-3 /5

Material Chrome Steel / Stainless Steel
Inner Ring with Inner Ring
Row Double Row

Dimensions(mm)(d*D*b)

15mm × 28mm × 13mm

Weight / Mass ( KG )

0.034kg

HS Code

8482800000
Original Country Show CHINA

Bearings Detailed Pictures :

Wearproof Torrington Needle Bearings Catalog For Printing Machine

Wearproof Torrington Needle Bearings Catalog For Printing Machine

Wearproof Torrington Needle Bearings Catalog for Printing Machine​ , Get Cheap Price from China Bearing Factory Now !

Contact With Us Freely :

Wuxi FSK Transmission Bearing Co., Ltd
Wearproof Torrington Needle Bearings Catalog For Printing Machine Sales Manger Kayee Fan
Whatsup/Viber: 8613771025202
Mail: fskbearing@yahoo.com
QQ: 207820856
Website: www.tapered-rollerbearing.com
No. 900 North Jie Fang Road Wuxi Jiangsu China
