Specifications
Brand Name :
IKO / INA / FAG / NSK / NTN / FSK / OEM
Model Number :
RNA 4824
Certification :
ISO9001-2000 / SGS / BV / CE
Place of Origin :
CHINA
MOQ :
1 pcs-10pcs
Price :
Competitive Low Price
Payment Terms :
30% Deposit , Balance After BL Copy
Supply Ability :
100000pcs/month
Delivery Time :
3-7Days After Deposit
Packaging Details :
1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) PLASTIC TUBE PACKING / KRAFT PACKING
Model No. :
RNA 4824
Size :
130mm × 150mm × 30mm
Weight :
0.774kg
Inner Ring :
without Inner Ring
Vibration :
V4, V3, V2, V1
Material :
GCr15, GCr15SiMn, G20Cr2Ni4A
Description

Metric Needle Roller Bearings / Needle Bearing Rna 4824 For Spinning Machine

Description of Needle Roller Bearings :

Needle bearings have a large surface area that is in contact with the bearing outer surfaces. Additionally there is less added clearance so they are much more compact. The typical structure consists of a needle cage which orients and contains the needle rollers, the needle rollers themselves, and an outer race and sometimes housing itself. Radial needle bearings are cylindrical and use rollers parallel to the axis of the shaft. Thrust needle bearings are flat and use a radial pattern of needles. Full compliment bearings have solid inner and outer rings and rib-guided cylindrical rollers.

Full Models of Standard Needle Roller bearing :

Light series needle roller bearings (NK,NKI,NKS,NKIS)
Heavy series needle roller bearings (NA,RNA,RNA-RS,RNA-2RS)
Curve needle rollers (KR,CF,CR,CNBH)
Strut needle rollers (NART,NUTR,CCYR,STO,RSTO,NAST-ZZ)
Not obstructs side needle roller bearings(NAO,RNAO)
Needle roller-thrust ball bearings (NX,NX-Z,NKX,NKX-Z)
Needle roller-thrust cylindrical bearings (NKXR,NKXR-Z)
Radial needle roller-thrust cylindrical needle roller bearings (ZARN)
Thrust-cylindrical needle roller bearings (811,812,WS,GS)
Needle rollers and cages (K,KR,KS,KBK,KZK)
Drawn cup needle roller clutches and assemblies (HF,HFL)

NA Series Needle Roller Bearings Drawing :

Metric Needle Roller Bearings / Needle Bearing Rna 4824 For Spinning Machine

Needle Roller Bearings List :

code internal outer width
mm mm mm
needle roller bearing RNA 4822 120 140 30
needle roller bearing RNA 4824 130 150 30
needle roller bearing RNA 4826 145 165 35
needle roller bearing RNA 4828 155 175 35
needle roller bearing RNA 4830 165 190 40
needle roller bearing RNA 4832 175 200 40
needle roller bearing RNA 4834 185 215 45
needle roller bearing RNA 4836 195 225 45
needle roller bearing RNA 4838 210 240 50
needle roller bearing RNA 4840 220 250 50
needle roller bearing RNA 4844 240 270 50
needle roller bearing RNA 4848 265 300 60
needle roller bearing RNA 4852 285 320 60
needle roller bearing RNA 4856 305 350 69
needle roller bearing RNA 4860 330 380 80
needle roller bearing RNA 4864 350 400 80
needle roller bearing RNA 4868 370 420 80
needle roller bearing RNA 4872 390 440 80
needle roller bearing RNA 4876 415 480 100


Bearing Specification :

Model Number

RNA 4824

Part Name

Needle Roller Bearing

Brand

IKO / INA / FAG / NSK / NTN / FSK / OEM

Precision Rating

ABEC-3 / ABEC-5
Material Chrome Steel / Stainless Steel
Inner Ring without Inner Ring
Row Single Row

Dimensions(mm)(d*D*b)

130mm × 150mm × 30mm

Weight / Mass ( KG )

0.774kg

HS Code

8482800000
Original Country Show CHINA

Bearings Detailed Pictures :

Metric Needle Roller Bearings / Needle Bearing Rna 4824 For Spinning Machine

Metric Needle Roller Bearings / Needle Bearing Rna 4824 For Spinning Machine

The Other Bearings We Do

Ball Bearing Deep Groove Ball Bearing 60 **,618 ** (1008), 619**(1009),62 **, 63 **, 64 **,
160 **(70001 )
Thrust Ball Bearing 511 ** (81) ,512 **(82) ,513 (83) ,514 ** (84) series and Angular Contact Thrust all Bearings like: 5617 ** (1687) ,5691 ** (91681), 5692 ** (91682) series
Angular Contact Ball bearing SN718 **(11068 ) ,70 ** 72 **,73 **, and B (66), C (36), AC (46) series ; otherwise include QJ and QJF series
Roller Bearing Spherical Roller bearing 239**, 230**,240**, 231**, 241**, 222**, 232**, 223**, 233**, 213**, 238**, 248**, 249**and special series include 26** i.e 2638 (3738), 2644 (3844) and so on
Taper Roller Bearing 329**(20079),210**(71), 320**(20071),302**(72), 322**(75), 303**(73), 313**(273),323**(76), 3519**(10979), 3529**(20979),3510**(971), 3520**(20971),3511**(10977), 3521**(20977), 3522**(975), 319**(10076),3819**(10779),3829**(20779), 3810**(777,771), 3820**(20771), 3811**(10777,777) for example: 77752, 77788, 77779 and also include Inch series bearings suchas 938/932 single and double row i.e M255410CD etc.
Thrust Roller Bearing 292**(90392), 293**(90393),294**(90394),994**(90194), and 9069 series.
Cylindrical Roller Bearing NU10**, NU2**,NU22**, NU3**,NU23**, NU4**, N, NJ ,NUP series as well as NB, NN, NNU series of big bearings, and we also have Split Bearings 412740, 422740 used in cement industry.And FC, FCD series used in Steel Industry.
