CK A2563 T Cam Clutch Wedge Type Overrunning One Way Clutch Bearing Backstop
CK A2563 T Cam Clutch Wedge Type Overrunning One Way Clutch Bearing Backstop
CK A2563 T Cam Clutch Wedge Type Overrunning One Way Clutch Bearing Backstop
CK A2563 T Cam Clutch Wedge Type Overrunning One Way Clutch Bearing Backstop
CK A2563 T Cam Clutch Wedge Type Overrunning One Way Clutch Bearing Backstop
CK A2563 T Cam Clutch Wedge Type Overrunning One Way Clutch Bearing Backstop
Specifications
Brand Name :
FSKG / KBE / TSUBAKI / OEM / Any Brand
Model Number :
CK-A2563T
Certification :
ISO9001-2000 / CE / ROHS / UL
Place of Origin :
CHINA
MOQ :
1 pcs
Price :
Talk in the letter
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
100000pcs/month
Delivery Time :
5-7Days After Details Confirmed
Packaging Details :
1)COLOURED SINGLE BOX PACKING + CARTON BOX PACKING + PALLETS , 2) INDUSTRIAL PACKING
Model :
CK A2563T
Application :
for Hoist
Same Model :
CK A2563T bearing / CK A2563 T bearing / CK-A2563T bearing
Material :
Gcr15
Part Name :
One Way Clutch Bearing
Package :
Single Carton Box / Pallet / Wooden case
Description

One-way CK-A2563T Wedge-type Overrunning Clutch Bearing Backstop Bearing for Hoist

Bearing Specification :

Model Number

CK-A2563T

Part Name

One Way Clutch Bearing

Brand

FSKG / KBE / TSUBAKI / OEM / Any Brand

Material

Gcr15 Chrome Steel
Package Single Carton Box / Pallet / Wooden case
Dimesions 25 x 63 x 32mm
Weight 0.68kg
HS Code 8482800000
Original Country Show CHINA
Application Hoist Machine

Bearing Drawing:

CK A2563 T Cam Clutch Wedge Type Overrunning One Way Clutch Bearing Backstop

Bearing photo:

CK A2563 T Cam Clutch Wedge Type Overrunning One Way Clutch Bearing Backstop

CK A2563 T Cam Clutch Wedge Type Overrunning One Way Clutch Bearing Backstop

Other Models We Can Offer

Model Nominal torque Tn(N.m) Axis maximum transcendental speed n(r/min) Outer Ring Inner Ring Mass m (kg)

ID

D (h7)

Key

(b×t)

Width

L

id

d (H7)

 Key (b1×t1) Width L1
CK-A2052 95 1400 52 3×1.8 23 20 3X1.4 24 0.25
CK-A2562 145 1260 62 4×2.5 23 25 4X1.8 24 0.35
CK-A3072 208 1050 72 5X3 23 30 5X2.3 24 0.47
CK-A3580 340 815 80 8X4 28 35 6X2.8 30 0.69
CK-A4090 462 700 90 8X4 28 40 6X2.8 30 0.87
CK-A45100 783 560 100 8X4 28 45 6X2.8 30 1.07
CK-A50110 850 525 110 10X5 28 50 8X3.3 30 1.59
CK-A60130 1050 490 130 10X5 34 60 8X3.3 36 2.16
CK-A65140 1224 490 140 10X5 34 65 10X3.3 36 2.49
CK-A70150 1850 455 150 10X5 40 70 10X3.3 42 3.36
CK-A75160 2140 455 160 12X5 40 75 12X3.3 42 3.81
CK-A80170 2450 420 170 12X5 40 80 12X3.3 42 4.29
CK-A1250 31.5 1750 50 3X1.8 22 12 3X1.4 24 0.24
CK-A1855 50 1575 55 4X2.5 22 18 4X1.8 24 0.28
CK-A2060 63 1600 60 6X3.5 22 20 6X2.8 24 0.33
CK-A2563 100 1260 63 6X3.5 24 25 6X2.8 26 0.37
CK-A2563T 140 1260 63 6X3.5 30 25 8X3.3 32 0.68
CK-A2870 180 1050 70 8X4 30 28 8X3.3 32 0.6
CK-A3080T 340 875 80 8X4 30 30 8X3.3 32 0.75
CK-A3585 400 815 85 8X4 30 35 8X3.3 32 1
CK-A35100 780 875 100 10X5 32 35 10X3.3 34 1.34
CK-A35140 1000 490 140 4XΦ8 35 35 10X3.5 35 3.28
CK-A40100 780 560 100 10X5 34 40 10X3.3 34 1.2
CK-A40110 850 700 110 10X5 32 40 10X3.3 34 1.19
CK-A50125 1000 490 125 14X5.5 36 50 14X3.8 35 2.21
CK-A50130 1050 560 130 14X5.5 36 50 14X3.8 38 3.02
CK-A55160 2000 455 160 16X6 52 55 16X4.3 55 6.96
CK-A58130 1050 490 130 14X5.5 36 58 14X3.8 38 2.6
CK-A60180 2000 420 180 6-M8 52 60 18X4.4 52 7.4
