HSO2004-M ONU CATV , GPON ONU Module Optical Connector SC/UPC
HSO2004-M ONU CATV , GPON ONU Module Optical Connector SC/UPC
HSO2004-M ONU CATV , GPON ONU Module Optical Connector SC/UPC
HSO2004-M ONU CATV , GPON ONU Module Optical Connector SC/UPC
HSO2004-M ONU CATV , GPON ONU Module Optical Connector SC/UPC
HSO2004-M ONU CATV , GPON ONU Module Optical Connector SC/UPC
Specifications
Brand Name :
HUANSHUN
Model Number :
HSO2004-M
Place of Origin :
CHINA
Certification :
China Telecom, Radio and Television and CCC Certification
MOQ :
100pcs
Price :
Negotiable
Packaging Details :
safety packing
Delivery Time :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram/Paypal
Description

2. GPON ONU Module

Summary

HSO2004-M is the ONU module in the GPON system user end equipment, and is used to terminate the service transmitted from the OLT (optical line terminal) through the GPON passive optical network. In conjunction with the OLT, the ONU can provide various broadband services to connected users. This machine meets the requirements of the corresponding ONU equipment in the "YD/T 1475-2006 Access Network Technical Requirements - Ethernet-based Passive Optical Network (EPON)" and "China Telecom GPON Equipment Technical Requirements". Ministry of Industry and Information Technology telecommunications equipment network license. This product satisfies the application of FTTX and FTTH in the two-way network of broadcasting and TV, and supports hybrid networking with mainstream OLTs to minimize the cost of network construction for operators. The Ethernet port specification is 4EF or 1GE+3FE.

Features

█ Its host performance is tested by the ministry of industry and information technology and licensed for telecommunications equipment;

█ The performance of the whole machine is tested by electromagnetic compatibility and safety. Obtained the national compulsory product certification (2015011608758829);

█ Ethernet port specifications are available in 4FE or 1GE+3FE, compatible with mainstream OLT vendors;

█ Modular structure, plug and play on demand.

Technical Specifications

Item Unit HSO2004-M HSO2004G-M
Optical Characteristics Working Wavelength nm TX1310, RX1490
Optical Transmission Power dBm 0～+4
Optical Receiving Sensitivity dBm ≤-29
Optical Connector / SC/UPC
Ports User End Ethernet Port pcs 4(10/100Mbps) 1(1000Mbps)+3(10/100/1000Mbps)
Others Power Supply /Consumption V/W Powered by the Host, DC12(0.5A)/3.5
Working/Storage Temperature ℃ -25~55/-40~75(Humidity 8~80%)
Structure Size mm 115×105×20

Application

HSO2004-M ONU CATV , GPON ONU Module Optical Connector SC/UPC

Order Info.

Product Name Model Description
GPON ONU Module HSO2004-M GPON 4FE, DC12V 0.5A Power Supply
HSO2004G-M GPON 1GE+3FE, DC12V 0.5A Power Supply
