Montage Chipset Small Set Top Box Support USB 2.0 PVR HD Decoder
Montage Chipset Small Set Top Box Support USB 2.0 PVR HD Decoder
Montage Chipset Small Set Top Box Support USB 2.0 PVR HD Decoder
Montage Chipset Small Set Top Box Support USB 2.0 PVR HD Decoder
Montage Chipset Small Set Top Box Support USB 2.0 PVR HD Decoder
Montage Chipset Small Set Top Box Support USB 2.0 PVR HD Decoder
Montage Chipset Small Set Top Box Support USB 2.0 PVR HD Decoder
Montage Chipset Small Set Top Box Support USB 2.0 PVR HD Decoder
Specifications
Brand Name :
JIZHONG
Model Number :
DCR-860J
Certification :
ISO9001,CE
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
100000Pcs/M
Packaging Details :
10PCS/CTN,CTN SIZE:42*37*27CM
STB Type :
Small Set Top Box
Main Chipset :
Montage
Symbol Rate :
3.61~6.952 Mbauds
Conditional Access :
Dexin
RAM :
128M
Flash :
8M
Demodulation :
16QAM,32QAM,64QAM,128QAM,256QAM
Channel Bandwidth :
6MHz,7MHz,8MHz
Description

Montage Chipset Small Set Top Box Support USB 2.0 PVR HD Decoder

Features

  • Adopt advanced QAM demodulation/MPEG-2/MPEG-4/H.264/AVS+ decode technology,which able to receive and decode digital TV program from DVB/MPEG/H.264/AVS/AVS+ compatible with CATV network.
  • Support multiple conditional Access system encoder way.EPG and advertisement business.Support finance and economics platform and information customization service.
  • Support PVR reservation,record and decode function.
  • Simple and straightforward operation interface,variety program
  • High efficient user experience,brings more convenience and humanization

Specifications

Frequency 47-862MHz
Channel Standard DVB-C EN300 429
Modulate type 16/32/64/128/256QAM
Symbol Rate 3.6-6.952MS/s
Video Decode MPEG-2MP@ML/MPEG4SP@ASP/Divx/AVS/AVX+/Real/VC-1/H.264/H.265
Video output 1080P50(60)/1080i/720p/576p
Audio encode MPEG-1(layer1&2/MPEG-2/AAC/AC3/RA/WMA/Dol by digital plus
Audio mode L/R/STO
CPU process speed @700MHz
FLASH 8MB
RAM 128MB
Display POW/CLOCK LED indicator
Panel Button Standby/channel
RF input British F type
Audio output PJ-322(L/R/CVBS)
HDMI output HDMI1.3b(HDCP)
USB USB2.0
IR loop out Mini USB-RS232
Input voltage DC:12V/0.8A
Power consumption 10W(max)
Dimension 112*112*24mm

Hardware Features

Montage Chipset Small Set Top Box Support USB 2.0 PVR HD Decoder

Accessories

RCU 1*RCU
Power Adaptor 1*External Power adaptor
User Manual 1*Single sheet user manual
HDMI Cable 1*HDMI Cable
A/V cable 1*A/V cable

Packing

Montage Chipset Small Set Top Box Support USB 2.0 PVR HD Decoder
