Specifications
Place of Origin :
China, Guang dong
Brand Name :
Hioso
Model Number :
FOWAY1309PFC
MOQ :
1-99 Pieces
Price :
Negotiable
Certification :
CE, RoHS, CCC
Payment Terms :
D/A, D/P, T/T, Western Union,
Supply Ability :
1000pcs/month
Delivery Time :
5-10working days
Packaging Details :
60*45*34cm Carton
Item :
8 port poe switch
Transmission rate :
1000Mbps
Function :
POE,Industrial
MAX output power :
250W ( single port:15.4W)
Power supply :
AC110V/220V
POE Standard :
IEEE802.3AF/AT
Description

Poe Ethernet Switch Network 8 Ports with 1 Gigabit Combo Port DC48V

Product Description

Network 8 Ports Poe Ethernet Switch with 1 Gigabit Combo 48V for Hikvision IP Camera

Character

l Support Maximum 8 100M PoE ports and 1 1000M Combo port (100M/1000M SFP port and 10/100/1000M RJ45 port optional)

l Each PoE port supports to auto discovery the standard power receiving devices

l Support IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards

l Support each port full rate, full-duplex non-blocking forwarding

l Support 8K MAC learning, 1Mbit storage and forward cache space, 4.6G back plane bandwidth

l Each RJ45 port using anti-high voltage circuit, strengthen the lightning protection and anti-interference ability

l Support to provide wall-mounted hanger better for installation if need, metal casing better for heat dissipating

Poe Ethernet Switch Network 8 Ports with 1 Gigabit Combo Port DC48VPoe Ethernet Switch Network 8 Ports with 1 Gigabit Combo Port DC48VPoe Ethernet Switch Network 8 Ports with 1 Gigabit Combo Port DC48V

Technical Specification

Parameter

Specification

Standard

IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX Gigabit Ethernet, IEEE802.3af, IEEE802.3at, IEEE802.1d Spanning Tree

PoE

Power supply ports: 8 ports

Standard and power consumption: IEEE802.3af 15.4W, IEEE802.3at 30W

Working mode: auto discovery power receiving devices and auto power supply/ cutting

Wavelength

SFP modules: 850nm/1310nm/1490nm/1550nm

Distance

100M SFP multi-mode: 2Km

Single-mode: 20/40/60/80/100/120Km

Single-fiber single-mode: 25/40/60/80/100/120Km

1000M SFP multi-mode: 220m (fiber 62.5/125μm)/ 550m (fiber 50/125μm)

Single-mode:10/20/40/60/80/100/120Km

Single-fiber single-mode: 10/20/40/60/80/100/120Km
Cat5:100m

Port

8 100M RJ45 ports (PoE optional): 10/100Mbps

1 1000M Combo port: 1 Gbps, 100M/1000M SFP&10/100/1000M RJ45

MAC

8K

Buffer memory space

1Mbit

Bit error rate

<1/1000000000

MTBF

100000 hours

Power

DC48V(External power), AC110V/220V & DC48V redundant power back up(Internal power)

Power consumption

10W

Working temperature

-10~60℃

Storage temperature

-40~80℃

Humidity

5%~90% non-condensing

Dimension

28mm (H)×193mm(W)×119mm (D)
