HiOSO 2Mbits Storage 8 1000M PoE Ports 2 1000M SFP Ports POE Switch
HiOSO 2Mbits Storage 8 1000M PoE Ports 2 1000M SFP Ports POE Switch
HiOSO 2Mbits Storage 8 1000M PoE Ports 2 1000M SFP Ports POE Switch
HiOSO 2Mbits Storage 8 1000M PoE Ports 2 1000M SFP Ports POE Switch
HiOSO 2Mbits Storage 8 1000M PoE Ports 2 1000M SFP Ports POE Switch
HiOSO 2Mbits Storage 8 1000M PoE Ports 2 1000M SFP Ports POE Switch
HiOSO 2Mbits Storage 8 1000M PoE Ports 2 1000M SFP Ports POE Switch
HiOSO 2Mbits Storage 8 1000M PoE Ports 2 1000M SFP Ports POE Switch
Specifications
Brand Name :
Hioso
Model Number :
FOWAY1510PFS
Certification :
CE, RoHS, CCC
Place of Origin :
China, Guang dong
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C, D/A
Supply Ability :
3000pcs/month
Delivery Time :
3-11 working days
Packaging Details :
50X35X15 cm
Item :
10 port poe switch
Function :
POE,Industrial
MAX output power :
120W ( single port:15.4W)
Power supply :
AC110V/220V
POE Standard :
IEEE802.3AF/AT
Package Type :
Standard packing
Description

10 Ports 1000Mbps Poe Switch 8 1000M PoE Ports + 2 1000M SFP Ports

Character

  • Each PoE port supports to auto discovery the standard power receiving device
  • Support IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards
  • Support 1000M port full rate, full-duplex non-blocking forwarding
  • Support 16K MAC learning, 2Mbits storage and forward cache space,18G back plane bandwidth
  • Each RJ45 port using anti-high voltage circuit, strengthen the lightning protection and anti-interference ability
  • Support to choose one side with fixed metal casing, external power design, better for heat dissipating and installation

Technical Specification

Parameter Specification
Standard IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX Fast Ethernet, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX Gigabit Ethernet, IEEE802.3af, IEEE802.3at, IEEE802.1d Spanning Tree
PoE

PoE ports: 4 ports or 8 ports

Standard and power consumption: IEEE802.3af 15.4W, IEEE802.3at 30W

Working mode: auto discovery power receiving devices and auto power supply/power cutting
Wavelength SFP Module: 850nm/1310nm/1490nm/1550nm
Distance

100M SFP multi-mode: 2Km

Single-mode: 20/40/60/80/100/120Km

Single-fiber single-mode: 25/40/60/80/100/120Km

1000M SFP multi-mode:220m (fiber 62.5/125μm) / 550m (fiber 50/125μm)

Single-mode:10/20/40/60/80/100/120Km

Single-fiber single-mode: 10/20/40/60/80/100/120Km
Cat5:100m
Port

8 1000M RJ45 ports (PoE optional): 10/100/1000Mbps

2 1000M SFP ports: 1000M SFP
MAC 16K
Buffer memory space 2Mbit
Bit error rate <1/1000000000
MTBF 100000 hours
Power DC48V(External power), AC110V/220V & DC48V redundant power back up(Internal power)
Power consumption 11W

Working

temperature

 -10~60℃
Storage temperature -40~80℃
Humidity 5%~90% non-condensing
Dimension 28mm (H)×193mm(W)×119mm (D)

HiOSO 2Mbits Storage 8 1000M PoE Ports 2 1000M SFP Ports POE Switch

HiOSO 2Mbits Storage 8 1000M PoE Ports 2 1000M SFP Ports POE Switch

FAQ
Q: Can you offer Technical Support after purchase?
A: YES, HSGQ technical department will be 24h stand by to solve your concerns.

Q: Do you accept Small Quantity Order?
A: Yes, we do accept a trial order to support you test the quality.

Q: What is your Lead Time for regular items?
A: Normal items, will delivery ASAP after payment 1-5 Days , for OEM / ODM, pls confirm the date with us.

Q: Do you offer Distributorship Abroad?
A: Yes, we are looking for a reliable business partner overseas market, welcomw to be HSGQ Exclusive Agent.

Q: What Payment Term can you provide?
A: Delivery Terms: FOB,CFR, CIF, EXW； Payment Currency: USD, CNY;
Payment Type: T/T,L/C,Western Union,Cash,Escrow;

Q: How about the Shipping?
A: For sample, about 5-7 days by fast delivery
For Mass order, about 15-25 days by sea, air, train shipping (after payment )
