1U Rack 8 1000M RJ45 2 SFP Ports POE 10 Port Switch POE 1000 Mbps
1U Rack 8 1000M RJ45 2 SFP Ports POE 10 Port Switch POE 1000 Mbps
1U Rack 8 1000M RJ45 2 SFP Ports POE 10 Port Switch POE 1000 Mbps
1U Rack 8 1000M RJ45 2 SFP Ports POE 10 Port Switch POE 1000 Mbps
1U Rack 8 1000M RJ45 2 SFP Ports POE 10 Port Switch POE 1000 Mbps
1U Rack 8 1000M RJ45 2 SFP Ports POE 10 Port Switch POE 1000 Mbps
1U Rack 8 1000M RJ45 2 SFP Ports POE 10 Port Switch POE 1000 Mbps
1U Rack 8 1000M RJ45 2 SFP Ports POE 10 Port Switch POE 1000 Mbps
Specifications
Brand Name :
Hioso
Model Number :
Foway2510PFST
Certification :
CE, RoHS, CCC
Place of Origin :
China, Guang dong
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
5000pcs/month
Delivery Time :
2-12 work days
Packaging Details :
38X24X18 CM
Product Name :
Poe switch
Poe :
8 Poe ports
Port :
2 sfp ports
Transmission :
CAT5 : 100M
Humidity :
5%~90%
Installation :
1U rack
Description

10 Ports Security PoE Switch 8 1000M RJ45 + 2 1000M Sfp Uplink Ports

Overview

HiOSO Foway2510PFST series 10 ports 1000M Security Industrial PoE Ethernet Switches, supply 8 10/100/1000M RJ45 PoE ports and 2 1000M SFP cascaded/ring network uplink ports ; support auto discovery IEEE802.3af/at standard powered devices,auto stop powering the non standard poe devices;support to supply power to IP cameras,VoIP phones,wireless access points and other network devices;support to choose web or SNMP management; support to transmit HD video flow; apply to Security system, electronic power system and traffic system requirements.

Technical Specification

Parameter Specification
PoE

8 PoE/PSE ports, support IEEE802.3af 15.4W / IEEE802.3at 30W

Working mode:auto detect powered device,stop powering if not PD device
Wavelength 850nm/1310nm/1490nm/1550nm/
Transmission distance 1000M Fiber,multi-mode:220m(fiber size 62.5/125μm)/550m(fiber size 50/125μm); Single-mode:10/20/40/60/80/100/120Km;Single-fiber:10/20/40/60/80/100/120Km CAT5: 100M
Ports

8 1000M RJ45 ports (POE/PSE): 10/100/1000Mbps

2 1000M SFP ports: 1 Gbps, 1000M SFP / 1000M Copper SFP
MAC 16K
Buffer memory space 2Mbit
Bit error rate <1/1000000000
MTBF 100000 hours
Power

DC48V dual input redundant backup (external power)

AC110V/220V@50HZ/60HZ&DC48V dual input redundant backup (inside power)

1U Rack 8 1000M RJ45 2 SFP Ports POE 10 Port Switch POE 1000 Mbps

1U Rack 8 1000M RJ45 2 SFP Ports POE 10 Port Switch POE 1000 Mbps

FAQ

1.Q: Could I put my own logo on the products?
A: Sure, your logo can be put on every product, either by laser, or by moulds.

2.Q: Could I put my own designs of label on the products?
A: Of course, you can send us your design, we'll follow your design.

3.Q: Can I have some samples before formal order?
A: Yes. we can send you some free samples for your test before your order.

4.Q: How long is the lead time?
A: Normally we keep stock for most products, the lead time is 1-5 days as soon as the payment is released.
For customized products, it takes longer.

5.Q: How about the after-sale service? What's the Warranty terms?
A: We offer 12 months for every products we sold. If you meet any problems after sales, pis contact us freely,
we'll help solving the problems within 24 hours.

6.Q: Are you manufacturer or just dealer?
A: We're manufaturer, we do produce all products by ourself. Welcome to visit our plant at any time.
