8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports
8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports
8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports
8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports
8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports
8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports
8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports
8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports
Specifications
Brand Name :
Hioso
Model Number :
Foway2310PFSP
Certification :
CE, RoHS, CCC
Place of Origin :
China, Guang dong
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
5000pcs/month
Delivery Time :
3-10 working days
Packaging Details :
38X24X18 CM
Product Name :
10 ports poe switch
Wavelength :
850nm/1310nm/1490nm/1550nm
Bit error rate :
<1/1000000000
MTBF :
100000 hours
Working temperature :
-10~60℃
Storage temperature :
-40~80℃
Description

10 Ports PoE Switch 8 10 / 100M PoE Ports + 2 1000M SFP Ports

Overview

HiOSO Foway2310PFSP series 10 ports 100M/1000M Security Industrial PoE Ethernet Switches, supply 8 10/100M RJ45 PoE ports and 2 1000M SFP cascaded/ring network uplink ports ; support auto discovery IEEE802.3af/at standard powered devices,auto stop powering the non standard poe devices;support to supply power to IP cameras,VoIP phones,wireless access points and other network devices;support to choose web or SNMP management; support to transmit HD video flow; apply to Security system, electronic power system and traffic system requirements.

Character

  • Support 8 10/100M RJ45 PoE ports and 2 1000M SFP ports ring network/cascaded Uplink,SFP port supports hot swap
  • Each PoE port supports auto detect the powered device
  • Support IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards
  • Support to establish Gigabit fiber ring/cascaded network
  • Support each port full rate, full-duplex non-blocking forwarding
  • Support WEB management and SNMP (optional),support RSR (Rapid Super Ring) tech
  • 8K MAC learning, 1Mbit storage and forward cache space,7.6G back plane bandwidth
  • Each RJ45 port adopts anti-high voltage circuit, strengthen the lightning protection and anti-interference ability
  • Supply redundant dual power input ports, enhance reliability
  • Metal casing with Wall mounting design , better for heat dissipating and installation

Parameter Specification
Standard IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet,IEEE802.3z 1000Base-SX/LX Gigabit Ethernet,IEEE802.3x Flow control,IEEE802.1q VLAN,IEEE802.1p QoS, IEEE802.1d Spanning Tree,IEEE802.1w RSTP IEEE802.3af,IEEE802.3at
PoE

8 10/100M RJ45 PoE/PSE, support IEEE802.3af 15.4W / IEEE802.3at 30W

Working mode:auto detect powered device,stop powering if not PD device
Wavelength 850nm/1310nm/1490nm/1550nm/
Transmission distance 1000M Fiber,multi-mode:220m(fiber size 62.5/125μm)/550m(fiber size 50/125μm); Single-mode:10/20/40/60/80/100/120Km;Single-fiber:10/20/40/60/80/100/120Km CAT5: 100M
Ports

8 10/100M RJ45 ports (POE/PSE);

2 1000M SFP ports: 1 Gbps, 1000M SFP / 1000M Copper SFP
MAC 8K
Buffer memory space 1Mbit
Bit error rate <1/1000000000
MTBF 100000 hours
Power

DC48V dual input redundant backup (external power)

AC110V/220V@50HZ/60HZ&DC48V dual input redundant backup (inside power)
Power consumption Whole device:5.2W POE/PSE: maximum240W
Working temperature Common:-10~60℃; -T (wide temperature range):-40~75℃
Storage temperature -40~80℃
Humidity 5%~90% non-condensing
Installation Wall mounting type (external power), desk type/1U rack (inside power)
Dimension

30mm (H)×219mm(W)×119mm (D) (external power)

44mm (H)×276mm(W)×190mm (D) (inside power)

8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports

8 10/100M PoE Ports 2 1000M SFP Ports Poe Ethernet Switch 10 Ports
