Specifications
Brand Name :
Hioso
Model Number :
Foway 4510TFSM
Certification :
CE, RoHS, CCC
Place of Origin :
China, Guang dong
MOQ :
1
Price :
Negotiable
Payment Terms :
TT
Supply Ability :
5000pcs/month
Delivery Time :
2-12 working days
Packaging Details :
38X24X18 CM
Item :
Din Rail Switch
Support :
DIP Switch
Power1 :
DC 12/24/48V
Power2 :
AC 10~ 60 V
Working :
-40 ~ 85°C
Storage :
-40℃～85℃
Description

10 Ports Din Rail Ethernet Switch 8 1000M Rj45 + 2 1000M Sfp Ports

Character

  • 10 / 100 / 1000M adaptive RJ45 ports, with MDI and MDI-X auto recognition functions
  • Support 1000M SFP port, maximum transmission distance 120km
  • Provide 2 input : 10~ 60 VDC and 18 ~ 30VAC, reverse connection protection
  • Support DHCP,PPPoE,ACL,LLDP, RSR,switch time less than 20ms

  • Provide two wide voltage 10 ~ 60 VDC input; provide reverse connection protection

  • Support Web management, CLI and SNMPv1 / V2 / V3 management

  • Support VLAN, STP / RSTP fast spanning tree, trunk port aggregation, IGMP multicast

  • Support RSR (rapid super ring) redundant ring network technology

  • Support up to 10kbyte ultra long frame packet transmission, 22G backplane bandwidth

  • Each RJ45 electric port is added with anti high voltage circuit to improve the ability of lightning protection and anti high voltage interference

Technical Specification

Parameter Specification
Access mode 10/100/1000Mbps
Port

8 RJ45 ports: 10/100/1000M

2 1000M SFP: 1Gbps, 10/100M/1000M SFP or 10/100/1000M Copper SFP
Conversion mode Medium conversion, storing and forwarding/straight-through
MAC address table 16K
Buffer space 2Mbit
Flow control Full duplex state: flow control; half-duplex state: back pressure mode
Delay 1us
Bit error rate <1/1000000000
MTBF 100,000 hours
LED FX Link (fiber link/action), TP1/2/3/4/5/67/8 100M/1000M (twisted pair rate) , TP1/2/3/4/5/6/7/8 Link (twisted pair link/action);P1 (power supply P1 connected) ,P2(power supply P2 connected),SYS (system)
Power 12/24/48 VDC,18 ~ 30VAC input
Power consumption 6.5W
Installation Din rail installation, wall mounting installation
Dimensions 135mm×52mm×105mm (height * width * depth)
