Specifications
Brand Name :
Hioso
Model Number :
FC610B
Certification :
CE, RoHS, CCC
Place of Origin :
China, Guang dong
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
6000pcs/month
Delivery Time :
3-11 working days
Packaging Details :
30X25X15 CM
Name :
100m fiber media converter
Wavelength :
850nm/1310nm/1490nm/1550nm
Access mode :
10/100Mbps
Standard :
IEEE802.3 10Base-T Ethernet
Conversion mode :
Medium conversion, storing and forwarding mode
Flow control :
Full duplex state: flow control; half-duplex state: back pressure mode
Description

2 ports 10 / 100 Mbps Adaptive Fast Ethernet Fiber Media Converter

Feature

· Supporting the transmission of extra-long packets over VLAN;

· Supporting Quality of Service (QoS) and ensuring transmission of VoIP packets;

· Supporting Spanning Tree Protocol (STP) to form a redundant network;

· Extremely low power consumption (less than 2W), low heat and capable of stable operation for a long period of time;

· Supporting multiple types of fiber ports such as dual-fiber multi-mode,dual-fiber single-mode and single-fiber single-mode, to satisfy the extended requirements of users.

Application
10/100Mbps fast optical Ethernet network with long-distance transmission

Technical Specification

Parameters Specifications
Access mode 10/100Mbps
Standard IEEE802.3 10Base-T Ethernet, IEEE802.3u, 100Base-TX/FX Fast Ethernet, IEEE802.3x Flow control, IEEE802.1q VLAN, IEEE802.1p QoS, IEEE802.1d Spanning Tree
Wavelength 850nm/1310nm/1490nm/1550nm
Transmission distance Dual-fiber single-mode: 25/40/60/80/100/120Km
Port Two RJ45 ports: Connected to STP/UTP category-5 twisted pairs
One fiber port: Multi-mode – SC or ST (fiber size: 50,62.5/125μm)
Single mode – SC/FC fiber port (fiber size: 9/125μm)
Conversion mode Medium conversion, storing and forwarding mode
MAC address table I K
Buffer space 512K bit
Flow control Full duplex state: flow control; half-duplex state: back pressure mode
Delay 9.6μs
Bit error rate <1/1000000000
MTBF 100,000 hours
LED POWER (power), FX LINK/ACT (fiber link/action), FX FDX (FX full duplex mode)
TP1 LINK/ACT (Port 1 twisted pair link/action), TP1 100 (port 1 twisted pair 100M transmission rate)
TP2 LINK/ACT (Port 2 twisted pair link/action), TP2 100 (port 2 twisted pair 100M transmission rate)
Power DC5V/1A (external)
Power consumption 3.2W
Operating temperature -10~55°C
Operating humidity 5%~90%
Storage temperature -40~70°C
Dimensions 26mm(H)*71mm(W)*95mm(D) (height * width * depth)

2 Ports 10/100 Mbps Fast Ethernet Fiber Media Converter Adaptive

2 Ports 10/100 Mbps Fast Ethernet Fiber Media Converter Adaptive

FAQ

Q1:How can I get your catalogue and price list?

A1:Please let us know your email or contact us from website directly for our catalogue and price list;

Q2: Can I negotiate the prices?

A2: Yes, we may consider discounts for multiple container load of mixed goods.

Q3: How much will the shipping charges be?

A3: It depends on the size of your shipment and the method of shipping.

We will offer the charge to you as you requested.

Q4: Can I visit you?

A4: Sure, our factory is in Shenzhen, China.Please contact us to make an appointment.
