Specifications
Brand Name :
Hioso
Model Number :
FC650E
Certification :
CE, RoHS, CCC
Place of Origin :
China, Guang dong
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
4000pcs/month
Delivery Time :
3-7 work days
Packaging Details :
30X25X15 CM
Product name :
Fiber mMedia Converter
Ports :
2 100M SC + 1 100M RJ45
Rate :
10/100M
MTBF :
100,000 hours
MAC address :
1k
Buffer space :
1M
Description

3 Ports Fiber Media Converter 2 100M Fiber Ports + 1 100M RJ45 Ports

Overview


HiOSO FC650E is a kind of 10/100Mbps adaptive fast Ethernet node type fiber media converter, with 1 10/100Mbps adaptive switch, which can implement mutual conversion between 10Base-T/100Base-TX twisted pair electrical signal and 100Base-FX optical signal. FC650F can extend the transmission distance of a network from 100m over copper wires to 120Km. This type of fiber converter supports two different types of network connection media types: 10/100Base-TX and 100Base-FX. With the application of the switching technology and the storing & forwarding technology, this kind of converter supports transmission in dual-fiber multi-mode,dual-fiber single-mode and single-fiber single-mode fibers.

Technical Specifications


Parameter		 Specifications
Access mode 10/100Mbps
Wavelength 850nm/1310nm/1550nm
Transmission distance Dual-fiber multi-mode: 2Km;
Dual-fiber single-mode: 25/40/60/80/100/120Km;
Single-fiber single-mode: 25/40/60/80/100Km
Category-5 twisted pair: 100m
Port 1 RJ45 connector, connected to STP/UTP category-5 twisted pair
Two fiber port: Multi-mode - SC or ST (fiber size: 50,62.5/125μm)
Single mode - SC/FC fiber port (fiber size: 9/125μm)
Single-fiber single-mode - SC/FC fiber port (fiber size: 9/125μm)
Conversion mode Medium conversion, storing and forwarding mode
MAC address table I K
Buffer space 1Mbit
Flow control Full duplex state: flow control; half duplex state: back pressure mode
Delay 9.6us
Bit error rate <1/1000000000
MTBF 100,000 hours
LED POWER (power), FX LINK/ACT (fiber connection/action)
FDX (FX full duplex mode), FX100 (Fiber, with a transmission rate of 100M)
TP1/2/3 LINK/ACT (1/2/3-port twisted pairs connection action)
TP1/2/3100 (1/2/3-port twisted pairs, with a transmission rate of 100M)
Power DC5V/1A (external)
Dimensions 26mm(Height)*70mm(Width)*98mm(Depth) (external power)
