HiOSO White 3U Rack 16 Slots Media Converter Chassis Dual Power Supply Fiber Converter Rack
HiOSO White 3U Rack 16 Slots Media Converter Chassis Dual Power Supply Fiber Converter Rack
HiOSO White 3U Rack 16 Slots Media Converter Chassis Dual Power Supply Fiber Converter Rack
HiOSO White 3U Rack 16 Slots Media Converter Chassis Dual Power Supply Fiber Converter Rack
HiOSO White 3U Rack 16 Slots Media Converter Chassis Dual Power Supply Fiber Converter Rack
HiOSO White 3U Rack 16 Slots Media Converter Chassis Dual Power Supply Fiber Converter Rack
HiOSO White 3U Rack 16 Slots Media Converter Chassis Dual Power Supply Fiber Converter Rack
HiOSO White 3U Rack 16 Slots Media Converter Chassis Dual Power Supply Fiber Converter Rack
Specifications
Place of Origin :
China, Guang dong
Brand Name :
Hioso
Model Number :
FTC-16
Certification :
CE, RoHS, CCC
Supply Ability :
2000pcs/month
Packaging Details :
56*40*36 cm
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Delivery Time :
3-10 working days
Name :
Converter Rack Chassis
Power :
dual power supply
Material :
metal
Slots :
16 slots
Height :
3U
Power input :
AC – Voltage: AC85 ~ 265V; frequency: 50/60 Hz DC – Voltage: DC -36 ~ 72V
Power output :
DC5V 16A
Rack dimensions :
132mm(H)*440mm(W)*220mm(D) / (height * width * depth)
Description

3U Rack Type 16 Port Fiber Media Converter Chassis Dual Power Supply

Overview


HiOSO FTC-16 fiber converter rack (3U) is a kind of economical converter rack used in machine rooms. The rack can accommodate maximum 16 different types of fiber converter module cards. There is an active and standby power system in a centralized manner, supporting automatic switching.

Technical Specification

Parameters Specifications
Number of slots 16
Structure 3U rack
Power input AC – Voltage: AC85 ~ 265V; frequency: 50/60 Hz
DC – Voltage: DC -36 ~ 72V
Power output DC5V 16A
Ripple ≤20mv
Power configuration Single power or dual power (in hot backup mode)
LED POWER (power)
Maximum power consumption 95W
Operating temperature -10~55°C
Operating humidity 5%~90%
Storage temperature -40~70°C
Storage humidity 5%~90% (non-condensing)
Rack dimensions 132mm(H)*440mm(W)*220mm(D) / (height * width * depth)
Module card dimensions 110mm(H)*22mm(W)*81mm(D) / (height * width * depth)

Feature

  • The active/standby power configuration ensures uninterrupted operation of the system;
  • Supporting two power supply modes: AC220V and DC -48V, so that the system is applicable to multiple operating environment;
  • Supporting the simultaneous operation of multiple types of module cards at different rates, greatly improving the system applicability;
  • Each module supports hot swapping;
  • Module cards supported: FC830AC series, FC610AC series, FC1000C series, FC1000AC series, FC1000FC series, FC155FC series and FC622FC series.

HiOSO White 3U Rack 16 Slots Media Converter Chassis Dual Power Supply Fiber Converter Rack

HiOSO White 3U Rack 16 Slots Media Converter Chassis Dual Power Supply Fiber Converter Rack

Datasheet download:FTC-16 Media Converter Rack.pdf

Our Service:
HiOSO provides technician team and special telephones to support after-sales service, customer can get answer and training from our technicians, the problem can be solved within 24 hours if there is anything with products. What's more, we provide free-exchange within one year, free-repair within three years and lifelong maintenance.

Our advantage:
Founded in 2002, Hioso Technology CO., Ltd. is the optic communication product manufacturer with 20 years experience. We engaged in the R&D, design, manufacture, sell FTTH and FTTD products all by ourselves and also provide OEM&ODM service for customers. We only provide cost-effective quality products and premium after-sale service.
