Specifications
Brand Name :
Hioso
Model Number :
FC540AG
Certification :
CE, RoHS, CCC
Place of Origin :
China, Guang dong
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, MoneyGram
Supply Ability :
6000pcs/month
Delivery Time :
2-7 working days
Packaging Details :
36X20X15 CM
Name :
Rail Type Media
Mounting :
Din rail
RJ45 port :
1 10/100/1000M
Power supply :
DC or AC
Operating :
-40~75°C
Storage :
-40~85°C
Description

1 Port Gigabit Fiber Media Converter 1 1000M Rj45 Port Rail Type Media

Feature

  • RJ45 port 10/100/1000M adaptive, with MDI and MDI-X auto recognition, automatic detection, automatic learning, good compatibility

  • Provide 2 RPS (Redundant power supply) input : 9.6 ~ 60 VDC and 18 ~ 30VAC

  • Provide reverse polarity protection

  • Support maximum 1536 byte long data packet transmission

  • Side of the DIP switch dial 1 is enabled broadcast storm, dial the disabled broadcast storm

  • With rugged metal housing IP30

  • Support rails or distribution cabinet installation

Parameters Specifications
Access mode 10/100/1000Mbps
Standard IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet,IEEE802.3ab 1000Base-T,IEEE802.3z 1000Base-SX/LX Gigabit thernet, IEEE 802.3x Flow Control,IEEE802.1d Spanning Tree,IEEE802.1q vlan,IEEE802.1p Qos
Wavelength 850nm/1310nm/1550nm
Transmission distance Dual-fiber multi-mode: 2Km; dual-fiber single-mode: 25/40/60/80/100/120Km;single-fiber single-mode: 25/40/60/80/100Km
Category-5 twisted pairs: 100m
Port One RJ45 port: Connected to STP/UTP category-5 twisted pairs
One fiber port: Multi-mode – SC or ST (fiber size: 50,62.5/125μm)
Single mode – SC/FC fiber port (fiber size: 9/125μm)
Single-fiber single-mode – SC/FC fiber port (fiber size: 9/125 μ m)
Conversion mode Medium conversion, storing and forwarding/straight-through
MAC address table 4 K
Buffer space 2Mbit
Flow control Full duplex state: flow control; half-duplex state: back pressure mode
Delay Storing & forwarding: 9.6 μ s; straight-through: 0.9 μ s;
Bit error rate <1/1000000000
MTBF 100,000 hours
LED FX LINK/ACT (fiber link/action)
SPD (twisted pair: transmission rate of 1000M) TP LINK/ACT (twisted pair link/action);P1 (power supply P1) ,P2(power supply P2)
Power 12/24/48 VDC,18 ~ 30VAC input
Power consumption 2.5W

1 Port Gigabit Fiber Media Converter 1 1000M Rj45 Port Rail Type Media

1 Port Gigabit Fiber Media Converter 1 1000M Rj45 Port Rail Type Media
