Indoor GPON ONU Huawei HG8546M Ont 4LAN+1POTS+1USB+ WIFI With English Version
Indoor GPON ONU Huawei HG8546M Ont 4LAN+1POTS+1USB+ WIFI With English Version
Indoor GPON ONU Huawei HG8546M Ont 4LAN+1POTS+1USB+ WIFI With English Version
Indoor GPON ONU Huawei HG8546M Ont 4LAN+1POTS+1USB+ WIFI With English Version
Indoor GPON ONU Huawei HG8546M Ont 4LAN+1POTS+1USB+ WIFI With English Version
Indoor GPON ONU Huawei HG8546M Ont 4LAN+1POTS+1USB+ WIFI With English Version
Indoor GPON ONU Huawei HG8546M Ont 4LAN+1POTS+1USB+ WIFI With English Version
Indoor GPON ONU Huawei HG8546M Ont 4LAN+1POTS+1USB+ WIFI With English Version
Specifications
Brand Name :
Huawei
Model Number :
HG8546M
Place of Origin :
China
MOQ :
1Unit
Payment Terms :
T/T, L/C, Western Union, MoneyGram,Paypal
Supply Ability :
5000Unit/Month
Delivery Time :
5-10 work days
Packaging Details :
inner box+outer carton
Product name :
Huawei HG8546M
Type :
Huawei Ont
Uplink :
symmetric 1.25Gbps
Wifi :
IEEE802.11bgn
Power supply :
12V DC
Color :
White
Function :
1GE
Downlink :
10/100/1000Mbps
Application :
FTTH FTTB FTTX Network,Fiber to the home
Price :
Negotiable
Description

Huawei Ont HG8546M 4LAN+1POTS+1USB+ WIFI Onu Gpon Wifi With English Version

Description

The Echo Life HG8546M is an indoor optical network terminal (ONT) in Huawei FTTH solution. By using the GPON technology, ultra-broadband access is provided for home and SOHO users.

The HG8546M provides four GE auto-adapting Ethernet port. The HG8546M features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services.
Specification
Model Configuration Dimension/pcs
LAN Telephone Wifi PPPOE Firmware
HG8546M 1GE+3FE 1pots yes yes English 250*185*35mm/0.44kgs
Remarks External Antenna

Application and Advantage

1.Full compatible with ITU-T G.984.
2.Support port-based rate limitation and bandwidth control
3.Integrated OMCI remote configuration and maintenance function.
4.Support data enscryption, group broadcasting, port Vlan separation ,RSTP,etc.
5.Support Dynamic Bandwidth Allocation (DBA)
6.Support ONT auto-discovery/Link detection/remote upgrade of software;
7.Support VLAN division and user separation to avoid broadcast storm;
8.Support power-off alarm function ,easy for link problem detection
9.Support broadcasting storm resistance function
10.Support port isolation between different ports
11.Support ACL and SNMP to configure data packet filter flexibly
12.Specialized design for system breakdown prevention to maintain stable system
13.Support software online upgrading
14.EMS network management based on SNMP ,convenient for maintenance

Performance specification

Item Parameter
PON Interface 1*GPON interface, SC single-mode/single-fibre, uplink 1.25Gbps, downlink 2.5Gbps
User Ethernet Interface 4*FE/GE auto adaptive Ethernet interfaces, RJ45 connectors,1*WIFI
Power Interface 12V DC Power supply An external 12V 1A AC/DC power supplyadapter

PON Optical

Parameter

Wavelength: Tx 1310nm, Rx1490nm

Tx Optical Power: -1~4dBm Rx Sensitivity: -28dBm

Saturation Optical Power: -3dBm Connector Type: SC

Optical Fiber: 9/125um single-mode fiber
Data Transmission Parameter

PON Throughput: Downstream 950Mbps; Upstream 930Mbps

Ethernet: 4*100Mbps Packet Loss Ratio: <1*10E-12 latency: <1.5ms
Network Management Status monitor, Configuration management, Alarm management, Log management

English Software

Indoor GPON ONU Huawei HG8546M Ont 4LAN+1POTS+1USB+ WIFI With English VersionIndoor GPON ONU Huawei HG8546M Ont 4LAN+1POTS+1USB+ WIFI With English Version

Product details

Indoor GPON ONU Huawei HG8546M Ont 4LAN+1POTS+1USB+ WIFI With English VersionIndoor GPON ONU Huawei HG8546M Ont 4LAN+1POTS+1USB+ WIFI With English Version

Products feature and application

Fiberhome PORT HG8010 1GE/FE
AN5506-01A 1GE HG8010C 1FE
AN5506-01B 1GE+1POTS HG8040 4FE
AN5506-02B 2GE+1POTS HG8110 1POTS+1FE
AN5506-04A 4FE HG8110C 1POTS+1FE
AN5506-04B 4FE+2POTS HG8120 1POTS+2FE
AN5506-04FG 4FE+2POTS+WIFI HG8120C 1POTS+2FE
ZTE PORT HG8120 2FE+1POTS
ZXA10 F601 1GE HG8240C/F/R 2POTS+4FE
ZXA10 F612 2GE+1POTS HG8242 2POTS+4GE+1CATV
ZXA10 F607 2FE+1POTS HG8245 2POTS+4FE+USB+WiFi
ZXA10 F620 4GE+2POTS HG8245C/F/R 2POTS+4FE+USB+WiFi
ZXA10 F643 1GE HG8247 2POTS+4GE+USB+CATV+WiFi
ZXA10 F660 4FE+2POTS+WIFI+2USB HG8310 1FE
HG8310M 1GE
HG8345r 4FE+WIFI HG8311 1POTS+1FE
HG8346M 2POTS+4FE+USB+WiFi HG8321 1POTS+2FE
HG8346R 2POTS+4FE+USB+WiFi HG8321R 1POTS+2FE
HG8347r 2POTS+1GE+3FE+USB+WiFi HG8326r 2POTS+1FE+WIFI
HG8447 4POTS+4GE+USB+CATV+WiFi HG8340m 4FE
HG8540m 4FE HG8342 2POTS+4FE
HG8546m 1POTS+4GE+USB+WiFi HG8342M 2POTS+4FE
HG8342R 2POTS+4FE

Ordering information

Product name Product description
HG8546M 4LAN+1POTS+1USB+ WIFI

Application
Typical Solution : FTTH, TTTB, PON + EOC
Typical Business: INTERNET, IPTV, VOD, IP Camera
