3 Line 6 Axle Heavy Duty Utility Trailer Low Bed 1.5m Steel Plate Solid Crossbeam
3 Line 6 Axle Heavy Duty Utility Trailer Low Bed 1.5m Steel Plate Solid Crossbeam
3 Line 6 Axle Heavy Duty Utility Trailer Low Bed 1.5m Steel Plate Solid Crossbeam
3 Line 6 Axle Heavy Duty Utility Trailer Low Bed 1.5m Steel Plate Solid Crossbeam
3 Line 6 Axle Heavy Duty Utility Trailer Low Bed 1.5m Steel Plate Solid Crossbeam
3 Line 6 Axle Heavy Duty Utility Trailer Low Bed 1.5m Steel Plate Solid Crossbeam
3 Line 6 Axle Heavy Duty Utility Trailer Low Bed 1.5m Steel Plate Solid Crossbeam
3 Line 6 Axle Heavy Duty Utility Trailer Low Bed 1.5m Steel Plate Solid Crossbeam
Specifications
Brand Name :
Huilong
Model Number :
Heavy Duty Trailer
Certification :
ISO9001
Place of Origin :
Suizhou, China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 units per month
Delivery Time :
4~6 weeks
Packaging Details :
in nude or by wax
Axle Type :
6 Axle
Line No. :
3 Line
Cross Beam :
4# channel steel
Fence Material :
1.5m steel plate
Steel Spring :
10/10/10
Valid Capacity :
100T
Description

3 Line 6 Axle Heavy Duty Utility Trailer Low Bed 1.5m Steel Plate Solid Crossbeam

Description:

• Key Application

Low bed semi-trailer is called heavy-lift trailer and is proficient in transporting over 100tons heavy and large cargo, e.g. bridge construction facilities, mold facilities. Six axles and 12 tires make the load increase to 15%.

• 3 Line / 6 Axle

3 Line 6 Axle refers to 3 axles are juxtaposed and connected with the same side of one main beam. Hence, two main beams are equipped with six axles and designed with the integrally arched structure.

Advantages:

• Effectiveness Management

High-strength steel is lighter than common carbon steel. In the same load, the dead weight of the semi-trailer decrease to over 1.3ton. The effectiveness of the trailer can be greatly improved.

• Solid Crossbeam

The crossbeam is made of 14# channel steel and suffers uniform stress. The space between the tire and crossbeam is adequate. Hence, the crossbeam won't scrape the tire.

Specifications:

Main Beam

Q345 Steel;

The height of the beam is 500mm;

Upper plate: 18mm;

Middle plate is 12mm;

Down plate is 20mm
Cross Beam 14# channel steel
Side Beam 25# channel steel
King Pin 2” (50mm)or 3.5” (90mm) traction pin
Dimensions 13000*3000*1550mm
Floor 4mm diamond steel plate
Fence

1.5m steel plate 600mm height;

fence 1000mm+20mm top
Ladder 60T Heavy duty mechanical ladder (optional hydraulic ladder)
Suspension Type Common mechanical
Steel Spring 10/10/10
Axle 3 Axle , FUWA Brand
Wheel Rim 9.0-22.5 steel wheel rim
Tire Spec:12R22.5; Number of Tire:12 pieces
Brake Chamber 6 big chamber
Brake Valve KTL Brand/WABCO
Brake System Dual Line Brake system
Tool Box 2 set standard tool box
Light

Tail lamp with turn signal,

brake light & reflector,

side lamp etc.
Painting

1 coat of anticorrosive prime;

twice coats of final paint
Spare Tire Carriers 2 pieces
Leading Gear 28T Manual operating, Heavy duty landing gear
Tare Weight 12000Kg
Loading Capacity 100T
Axle Weight Load 13T
Configuration
3 Line 6 Axle Heavy Duty Utility Trailer Low Bed 1.5m Steel Plate Solid Crossbeam
