4 Axle Sea Container Trailer , 20ft Container Transport Trailer Diversified Fence Abrasive Blasting
4 Axle Sea Container Trailer , 20ft Container Transport Trailer Diversified Fence Abrasive Blasting
4 Axle Sea Container Trailer , 20ft Container Transport Trailer Diversified Fence Abrasive Blasting
4 Axle Sea Container Trailer , 20ft Container Transport Trailer Diversified Fence Abrasive Blasting
Specifications
Brand Name :
Huilong
Model Number :
Cargo Container Trailer
Certification :
ISO9001
Place of Origin :
Suizhou, China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 units per month
Delivery Time :
4~6 weeks
Packaging Details :
in nude or by wax
Axle Type :
4
Spring Config :
Leaf Spring or Air Bag
King Pin Brand :
JOST
No. of Container :
1x20ft, 2x20ft; 1x40ft
Tare Weight :
10500KGS
Brake Chamber :
T30/30+T30
Description

4 Axle Sea Container Trailer , 20ft Container Transport Trailer Diversified Fence Abrasive Blasting

Description:

• Core Application

The cargo trailer is the necessary vehicle for freight stations and courier companies. Simple bulk goods like articles for daily use and some engineering materials can be transported.

• Average Axle Load

The trailer with 4 axles is more flexible and steady. The large load is equally shared by each axle.

Advantages:

• Firm Structure

High-strength steel is used in the production of cargo trailers, which can improve the structural strength. The steel is welded by the skilled and mature technology. Bolt connection is applied in the side protection. Protective devices of rear end are welded with the frame.

• Diversified Fence

The height of the fence is modifiable. The quality of fence and back door varies within 3%. The shape of fence is selective, including vertical corrugated plate and square tube plate.

• Flexible Configuration

Three kinds of back door are offered in the rear end: flower-fence door, three folding door, and dual semi-closed door. Four to six side doors are provided for options.

• Abrasive Blasting

The surface of the metallic material is processed by the shot blasting machine. Then, a stress layer will be generated to protect the material against oxidation.

Specifications:

DIMENSIONS
Tare Weight 10500KGS Payload 45000KGS
Overall Length 12500mm Overall Width 2600mm
Technical Data
Chassis

Heavy duty and extra durability designed I beam;

Opting for high tensile steel Q345;

Welded by automatic Submerged-Arc processes;

Top Flange 14mm, width 140mm;

Middle Flange 6mm;

Bottom Flange 16mm, width 140mm
Axle 4 axles
Brand name: BPW, L1 or FUWA
Suspension Mechanical suspension or air suspension
Spring Leaf spring or air bag
King Pin JOST brand 2” Bolt-in King Pin
Landing Gear

JOST brand Two-speed;

manual operating;

heavy duty landing gear
Wheel Rim 8.5-20 ,9.0-20, 8.25-22.5, 9.0-22.5 steel wheel rim
Twist Lock 12 no. of ISO twist lock for 1x20ft, 2x20ft; 1x40ft container
Tyre 11.00R20 , 12.00R20, 11R22.5, 12R22.5, 315/80R22.5
Spare Tyre One set of spare tire including a carrier
Braking System

WABCO RE 6 relay valve;

T30/30+T30 Spring brake chamber;

40L air tanks
Painting

Complete Chassis sand blasting to clean rust;

1 coat of anticorrosive prime;

2 coats of final paint
Accessories One standard tool box
