14m Storehouse Cargo Container Trailer 40l Air Tank Steel Celiac Plate Cost Effective
14m Storehouse Cargo Container Trailer 40l Air Tank Steel Celiac Plate Cost Effective
14m Storehouse Cargo Container Trailer 40l Air Tank Steel Celiac Plate Cost Effective
14m Storehouse Cargo Container Trailer 40l Air Tank Steel Celiac Plate Cost Effective
14m Storehouse Cargo Container Trailer 40l Air Tank Steel Celiac Plate Cost Effective
14m Storehouse Cargo Container Trailer 40l Air Tank Steel Celiac Plate Cost Effective
Specifications
Brand Name :
Huilong
Model Number :
Cargo Container Trailer
Certification :
ISO9001
Place of Origin :
Suizhou, China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 units per month
Delivery Time :
4~6 weeks
Packaging Details :
in nude or by wax
Overall Length :
14000mm
Middle Flange :
6mm
Suspension Type :
Mechanical / Air Suspension
Relay Valve Qty :
6
Air Tank Volume :
40L
Axle Spec :
4
Description

14m Storehouse Cargo Container Trailer 40l Air Tank Steel Celiac Plate Cost Effective

Description:

• Chief Application

The cargo transport trailer can transport bulk goods in the area of agriculture, forestry, animal husbandry, and fishery etc. Customers’ requirements are considered during the design. The lightweight and large loads are reconciled in the vehicle structure. It is easy to dismantle and install components. Hence, the trailer is the ideal choice for transporting building materials and coal.

• Overlength Carriage

The length of the storehouse bulk cargo trailer is up to 14m. So it can transport long goods easily and has a large load.

Advantages:

• Advanced Design

The trailer is produced based on the advanced design concept at home and abroad, investigation on transportation environment of different areas, and multiple innovations.

• Durability and Fastness

The carriage is equipped with bending components and channel steels, which is the integration of bearing capacity and durability. Celiac plate, base plate and key parts are made of high-strength steel with advanced technical standards. The weight of several parts is reduced without affecting the structural strength. I beam prevents the shape from being deformed.

• Low Loss

The gravity center decreases to 1.3-1.4m and diminishes damages on tyres, leaf springs and frame.

• Mechanical Locking

Mechanical locking is applied in the rear side plate. During unloading, the lock hook and rear side plate are automatically opened to avoid block. The harm on the trailer is weakened and the working life is extended.

Specifications:

DIMENSIONS
Overall Length 14000mm
Technical Data
Chassis

Heavy duty and extra durability designed I beam;

Opting for high tensile steel Q345;

Welded by automatic Submerged- Arc processes;

Top Flange 14mm, width 140mm;

Middle Flange 6mm;

Bottom Flange 16mm, width 140mm
Axle 4 axles
Brand name: BPW, L1 or FUWA
Suspension Mechanical suspension or air suspension
Spring Leaf spring or air bag
King Pin JOST brand 2” Bolt-in King Pin
Landing Gear

JOST brand Two-speed;

manual operating;

heavy duty landing gear
Wheel Rim 8.5-20 ,9.0-20, 8.25-22.5, 9.0-22.5 steel wheel rim
Twist Lock 12 no. of ISO twist lock for 1x20ft, 2x20ft; 1x40ft container
Tyre 11.00R20 , 12.00R20, 11R22.5,12R22.5,315/80R22.5
Spare tyre One set of spare tire including a carrier
Braking System

WABCO RE 6 relay valve;

T30/30+T30 Spring brake chamber;

40L air tanks
Painting

Complete Chassis sand blasting to clean rust;

1 coat of anticorrosive prime;

2 coats of final paint
Accessories One standard tool box
Configuration
14m Storehouse Cargo Container Trailer 40l Air Tank Steel Celiac Plate Cost Effective
