Double Tyre Container Transport Trailer Heavy Duty Submerged Arc Welding
Double Tyre Container Transport Trailer Heavy Duty Submerged Arc Welding
Double Tyre Container Transport Trailer Heavy Duty Submerged Arc Welding
Double Tyre Container Transport Trailer Heavy Duty Submerged Arc Welding
Double Tyre Container Transport Trailer Heavy Duty Submerged Arc Welding
Double Tyre Container Transport Trailer Heavy Duty Submerged Arc Welding
Specifications
Brand Name :
Huilong
Model Number :
Cargo Container Trailer
Certification :
ISO9001
Place of Origin :
Suizhou, China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 units per month
Delivery Time :
4~6 weeks
Packaging Details :
in nude or by wax
Axle Mode :
4
Carrying Cap. :
45000KGS
Electric Arcs :
Submerged Arc Welding (SAW)
Tyre Model :
11.00R20 , 12.00R20, 11R22.5,12R22.5,315/80R22.5
Tare Weight :
10500KGS
Accessories :
One Standard Tool Box
Description

Double Tyre Container Transport Trailer Heavy Duty Submerged Arc Welding

Description:

• Chief Application

The heavy duty daily cargo transport trailer is a van semi-trailer equipped with a fence structure. The requested payload can be kept while the weight of the carriage is decreased. The trailer is generally used in the following fields: agriculture, power engineering, telecommunication engineering etc.

• Multi-Axle Layout

The heavy duty cargo transport trailer has 4 axles. The multi-axle layout is good for carrying massive goods with large weight. Our stake trailer has notable characteristics below: high braking performance, ergonomic design, reliable loading.

Advantages:

• Heavy-Duty

The allowable payload of the heavy duty daily cargo transport trailer is up to 45 tons. Compared with common trailers, more goods can be transported. Efficiency in transportation can be increased by 30-50%. Costs decease by 30-40% and oil wear decease by 20-30%. Thus, comprehensive economic benefits of road transport are greatly improved.

• Reasonable Structure

The cargo transport trailer adopts a spatial frame structure, which can balance the rigidity and toughness of the frame. Therefore, the bearing capacity is strong and the shape of the frame can be enduringly kept.

• Easy Loading and Unloading

There are 7 doors on each side of the trailer body. They can be handily opened when loading and unloading. The work efficiency is improved accordingly.

• Double Tyre

The dual tyre makes the driving safer and provides the safeguard for transporting heavy-duty cargo.

Specifications:

DIMENSIONS
Tare Weight 10500KGS Payload 45000KGS
Overall Length 12500mm Overall Width 2600mm
Technical Data
Chassis

Heavy duty and extra durability designed I beam;

Opting for high tensile steel Q345;

Welded by automatic Submerged-Arc processes;

Top Flange 14mm, width 140mm;

Middle Flange 6mm;

Bottom Flange 16mm, width 140mm
Axle 4 axles
Brand name: BPW, L1 or FUWA-optional upon choice
Suspension Mechanical suspension or air suspension
Spring Leaf spring or air bag
King Pin JOST brand 2” Bolt-in King Pin
Landing Gear

JOST brand Two-speed;

manual operating;

heavy duty landing gear
Wheel Rim 8.5-20 ,9.0-20, 8.25-22.5, 9.0-22.5 steel wheel rim
Twist Lock 12 no. of ISO twist lock for 1x20ft, 2x20ft; 1x40ft container
Tyre 11.00R20 , 12.00R20, 11R22.5,12R22.5,315/80R22.5
Spare Tyre One set of spare tire including a carrier
Braking System

WABCO RE 6 relay valve;

T30/30+T30 Spring brake chamber;

40L air tanks
Painting

Complete Chassis sand blasting to clean rust;

1 coat of anticorrosive prime;

2 coats of final paint
Accessories One standard tool box
Gallery
Double Tyre Container Transport Trailer Heavy Duty Submerged Arc Welding
