Gas Phase Valve LPG Tank Trailer Large Volume For Efficient Gas Transportation
Gas Phase Valve LPG Tank Trailer Large Volume For Efficient Gas Transportation
Gas Phase Valve LPG Tank Trailer Large Volume For Efficient Gas Transportation
Gas Phase Valve LPG Tank Trailer Large Volume For Efficient Gas Transportation
Gas Phase Valve LPG Tank Trailer Large Volume For Efficient Gas Transportation
Gas Phase Valve LPG Tank Trailer Large Volume For Efficient Gas Transportation
Specifications
Brand Name :
Huilong
Model Number :
LPG Tank Trailer
Certification :
ISO9001
Place of Origin :
Suizhou, China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 units per month
Delivery Time :
4~6 weeks
Packaging Details :
in nude or by wax
Gas Tank Capacity :
54.76CBM
Axle Supplier :
FUWA
Gas Tank Pressure :
1.77Mpa
Gas Tank Temperature :
50°
Tare Weight :
16800kgs
Wheel Rim :
9.0-22.5
Description

Gas Phase Valve LPG Tank Trailer Large Volume For Efficient Gas Transportation

Description:

The liquefied gas semi-trailer is the special-purpose vehicle that be designed to transport liquefied gas in above-second-class highway. Its design, fabrication, testing and inspection, and acceptance is accorded to ‘Supervision Rules for Safety of Liquefied Gas Auto Tanker’, ‘Supervision Regulations on Safety Technology of Pressure Vessels’, GB150-1998 ‘Steel Pressure Vessels ’and ‘The general technical requirements of semi-trailer’. It has many advantages, such as safe and reliable, economical and practical and overhauls conveniently.

Because of medium danger, for assuring safe operations, the user shall strictly confirm to the relative rules of ‘Supervision Rules for Safety of Liquefied Gas Auto Tanker’, ‘Supervision Regulations on Safety Technology of Pressure Vessels’ and ‘Operation Instruction of Liquefied Gas Semi-trailer’.

Cautions before Usage

Because of no-replacing with inert gases or no-drawing out air when the semi-trailer finished, before loading LPG, the inner of the tank and pipe (here is the position that is touched with LPG) shall be replaced with inert gases (Nitrogen gas N2), or be drawn out air to vacuum state and vacuum degree is not less to 650mm mercury-pole (or oxygen contain is not big than 3%). The purpose is to avoid possible exploding that is caused by the mixing of LPG and air.

Advantages:

  1. Strict procedure for safety loading and discharging
  2. Heavy duty and big volume for efficiency transport

Specifications:

Dimension
Overall Dimension 12600x2500x3900mm
Tare Weight 16800kgs
Tank
Tank Volume 54.76CBM
Payload 23000KGS
Tank Material 16MnR
Tank Design Pressure 1.77Mpa
Tank Design Temperature 50°
Corrosion Allowance 1.0mm
Hydraulic Test Pressure 2.66Mpa
Tank Parts
Loading Valve and Unloading Valve

Gas phase: DN25

Liquid phase: DN50
Emergency Shut Off Device

Gas phase: DN25

Liquid phase: DN50

Operating by hydraulic

Closing time: less than 10 sec
Safety Valve

Nominal diameter: DN80

Nominal pressure: PN2.5MPa

Open pressure: 1.86~1.94MPa

Closing pressure: 1.49~1.55MPa
Indicator Gauge

Rotary type

Surveying range: 0~2400mm

Precision: 2.5 Grade
Other Parts Pressure gauge, temperature meter
Trailer Chassis
Axle FUWA 13T axle
Suspension Mechanical suspension
Tyre 12R22.5
Wheel Rim 9.0-22.5
Accessory One standard tool box
Gallery
Gas Phase Valve LPG Tank Trailer Large Volume For Efficient Gas Transportation
