100 CBM LPG Storage Tank , Horizontal Lpg Tank Semi Trailer ISO9001 Certified
100 CBM LPG Storage Tank , Horizontal Lpg Tank Semi Trailer ISO9001 Certified
100 CBM LPG Storage Tank , Horizontal Lpg Tank Semi Trailer ISO9001 Certified
100 CBM LPG Storage Tank , Horizontal Lpg Tank Semi Trailer ISO9001 Certified
Specifications
Brand Name :
Huilong
Model Number :
LPG Tank Trailer
Certification :
ISO9001
Place of Origin :
Suizhou, China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 units per month
Delivery Time :
4~6 weeks
Packaging Details :
in nude or by wax
Vessel Capacity :
100CBM
Tank Model :
Horizontal
Container Type :
Chemical Tank
Corrosion Allowance :
1.0mm
Medium Density :
420kg/m3
Axle Qty :
3
Description

100CBM LPG Storage Tank

Description:

• Key Application
LPG storage tank is usually applied in the cryogenic liquid storage of various gas fuels. Other oil and chemical raw materials can be stored as well. The LPG vessel is diffusely used in many areas like: gas industry, hospital, smelting and cutting of metal. The 100CBM tank can satisfy the large gas consumption.

Advantages:

• Rotproof Tank
The surface of the tank is dealt with advanced technologies e.g.: sandblasting, spraying coat, sweeping etc.

• Light Running Gear
The light running gear maximizes the valid capacity and reduces operating costs.

• Stable Performance
The rigorous and scientific production technology ensures the minimum shrinkage ratio and the maximum stability in the low temperature.

• Customized Configuration
Depending on different mediums, the following tank material can be offered: carbon steel, stainless steel, manganese steel etc. The tank shape varies with transport requirements, including ellipse, monoblock, and round. Insulation devices can be optionally installed, like heating tube, thermal barrier etc. Air or mechanical suspension is equipped for customers' requirement.

Specifications:

Tank Tank Volume 100CBM
Model Horizontal
Type Chemical Tank
Applicable Material LPG
Design Pressure(MPa) 1.77
Max. Operating Pressure(MPa) 1.61
Hydrostatic Pressure(MPa) 2.22
Air Tight Pressure(MPa) 1.77
Corrosion Allowance 1.0mm
Design Temperature -19～50℃
Shell Thickness 18.47mm
Cap Thickness 18.42mm
Heat Treatment Overall
Tank Material 16MnR
Medium Density 420kg/m3
Other Parts

Thermometer

Pressure Gauge

Valve Box

Vent Valve

Handle

Soft Tightwire

Hose
Level Gauge Nominal Pressure 2.5MPa
Measurement Scale 50-3100mm
Accuracy 2.5
Safety Valve Nominal Diameter DN80
Breakout Pressure (BP) 1.68-1.76MPa
Reseating Pressure ≥BPx0.8
Cargo Handling Nominal Diameter Liquid Inlet Pipe DN50
Liquid Outlet Pipe DN80
Gas Inlet Pipe DN50
Drain DN80
Vent DN80
Trailer Chassis Axle 3 axle
Suspension Air/mechanical suspension
ABS Available
