46000 L Full Volume Fuel Tank Trailer , High End Fuel Transfer Trailer
46000 L Full Volume Fuel Tank Trailer , High End Fuel Transfer Trailer
46000 L Full Volume Fuel Tank Trailer , High End Fuel Transfer Trailer
46000 L Full Volume Fuel Tank Trailer , High End Fuel Transfer Trailer
46000 L Full Volume Fuel Tank Trailer , High End Fuel Transfer Trailer
46000 L Full Volume Fuel Tank Trailer , High End Fuel Transfer Trailer
Specifications
Brand Name :
Huilong
Model Number :
Fuel Tank Trailer
Certification :
ISO9001
Place of Origin :
Suizhou, China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 units per month
Delivery Time :
4~6 weeks
Packaging Details :
in nude or by wax
Full Volume(m3) :
46000L
I Beam :
Carbon Steel
Tank Shape :
Ellipse
Landing Gear :
Two-speed
King Pin :
JOST Brand
Manhole Standard :
API
Description

46000L Aluminum Fuel Tank Trailer

Description:

• Main Application


Oil transportation always occupies an important place in road transport. More and more gas stations appear in recent years. The fuel tank trailer can achieve the interregional line-haul of oil.

Advantages:

• Fuel-efficient Tank
The gross weight of the aluminium vehicle can be decreased to 30%~40%. 60% of fuel consumption comes from the tare weight of the trailer. The 100kg reduction of auto body mass can enable the 0.4L-0.8L deduction of fuel use.

• Renewable Trailer
Since aluminium alloy is an anticorrosion material, the damage to the scrap tank is less. 85% of the tank is renewable. The extension of the life of the tank is the direct interest.

Specifications:

Main Parameters
Overall Dimension 12100×2550×3800(mm)
Total Mass 40000(Kg)
Curb Weight 7000(Kg)
Rated Load 33000(Kg)
Fifth-wheel Load 16000(Kg)
Tank Body
Shape Ellipse
Total Volume(m3) 46000L
Tanker Body Material 6mm aluminium alloy
End Plate 7mm aluminium alloy
Manhole Cover

aluminium alloy API manhole cover;

Φ500mm;

2 sets with 2 breather valves
Bottom Valve 2 sets of pneumatic valve
Compartment 2
Discharging Valve 2 sets Φ100mm
Discharging Pipe 4” rubber hose, 2pcs, 6m long
Vapor Collecting System Standard
Anti-overflow Device Standard
Chassis
Main Beams

Special design carbon steel I beam;

Connected by bolts and nuts with tanker body;

Removable from tanker for separate transportation
Approach/Departure Angle -/16(°)
Axle BPW 13 Ton x3; -/24000
Landing Gear JOST brand Two-speed, manual operating, heavy duty
King Pin JOST brand 2” bolt-in
Suspension Non-liftable air suspension
Braking System

WABCO RE 6 relay valve;

T30/30+T30 Spring brake chamber;

40L air tanks
Rear Track 1860/1860/1860,1840/1840/1840,1820/1820/1820
Tire 11.00R20 12PR,12R22.5 12PR, 12 pieces
Painting

Sand blasting to clean rust;

1 coat of anticorrosive prime;

2 coats of final paint
Accessories Tool box
