Dongfeng 2 Axle Heavy Duty Trailer , Semi Low Bed Trailer 4X2 Wheel Mode
Dongfeng 2 Axle Heavy Duty Trailer , Semi Low Bed Trailer 4X2 Wheel Mode
Dongfeng 2 Axle Heavy Duty Trailer , Semi Low Bed Trailer 4X2 Wheel Mode
Dongfeng 2 Axle Heavy Duty Trailer , Semi Low Bed Trailer 4X2 Wheel Mode
Specifications
Brand Name :
Huilong
Model Number :
Heavy Duty Trailer
Certification :
ISO9001
Place of Origin :
Suizhou, China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 units per month
Delivery Time :
4~6 weeks
Packaging Details :
in nude or by wax
Axle No. :
13Tx2; FUWA
Chassis Supplier :
DONGFENG
Wheel Mode :
4X2
Baseplate :
3mm Diamond Plate
Flange Plate :
Top: 8mm; Bottom: 8mm
Web Plate :
12/14mm
Description

2 Axle Low Bed Trailer

Description:

• Wide Application
Low bed trailers usually transport inseparable large equipments like construction machineries etc. Ramps installed on the rear end can move mobile machines over vertical obstacles. Although general low bed trailers are widely used, the transportation is insecure due to the high bearing platform and complex loading. This foldable drop deck low bed trailer can adjust the height of the platform to fit the cargo.

Advantages:

• Sectional Structure
The lowboy trailer is designed with the concave beam. The coupling part of the frame is the platform. The rear wheel is arranged in the tailstock. The kingpin is inserted into the fifth wheel. The back of the gooseneck is connected with the main frame by the rotation shaft.

• Flexible Loading
The ground clearance still can be adjusted after loading the machinery. The trafficability can be improved by reducing or increasing the ground clearance when the semi-trailer confronts the obstacle over the cargo or runs on the bumpy road.
During transporting over-wide device, ladder-shaped supporters on both sides of the frame can be opened to increase the width of the platform. Moreover, devices can be fixed by rings nut welded on the outside of the frame.

Specifications:

Main Parameters
Dimension 11600×3000×3100 (mm)
Total Mass 35000(Kg)
Curb Weight 7500(Kg)
Rated Load 27500(Kg)
Running Gear
Axle Qty 13Tx2; FUWA
Landing Gear JOST, 26T
Kingpin JOST, 90#
Approach / Departure Angle -/21(°)
Axle Load -/18000
Tyre 8.25-20, 8.25R20, x8
Chassis
Chassis Manufacturer DONGFENG
Wheel Mode 4X2
ABS Yes
Front/Rear Suspension -/1300(mm)
Wheelbase 8540+1310(mm)
Leaf Spring -/4/4,-/10/10,-/8/8
Major Structure
Baseplate 3mm diamond plate
Flange Plate Top: 8mm; Bottom: 8mm
Web Plate 12/14mm
Main Beam I Beam
Accessories
Spare Tyre Rack 2
Tool Box 1
Gallery
Dongfeng 2 Axle Heavy Duty Trailer , Semi Low Bed Trailer 4X2 Wheel Mode
