3 Axle Container Delivery Trailer 40 Feet Container Hauler Trailer Enough Strength
3 Axle Container Delivery Trailer 40 Feet Container Hauler Trailer Enough Strength
3 Axle Container Delivery Trailer 40 Feet Container Hauler Trailer Enough Strength
3 Axle Container Delivery Trailer 40 Feet Container Hauler Trailer Enough Strength
3 Axle Container Delivery Trailer 40 Feet Container Hauler Trailer Enough Strength
3 Axle Container Delivery Trailer 40 Feet Container Hauler Trailer Enough Strength
3 Axle Container Delivery Trailer 40 Feet Container Hauler Trailer Enough Strength
3 Axle Container Delivery Trailer 40 Feet Container Hauler Trailer Enough Strength
Specifications
Brand Name :
Huilong
Model Number :
Cargo Container Trailer
Certification :
ISO9001
Place of Origin :
Suizhou, China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 units per month
Delivery Time :
4~6 weeks
Packaging Details :
in nude or by wax
Amount of Axle :
3
Suspension :
Mechanical suspension
King Pin :
FUWA brand 2” Bolt-in King Pin
Twist Lock :
12 no. of ISO Twist Lock
Welding :
Submerged Arc Welding
Tyre :
12R22.5 tire, 12PCS
Description

43 Axle Cargo Container Trailer 40FT Container Hauler Trailer Enough strength

Description:

Key application

Skeleton container trailer is a kind of semi-trailer frame for container transportation. Mainly used in shipyard, port, route, highway, transfer station, bridge, tunnel, multi-modal transport logistics system.

Advantages:

• Enough strength

It is specially used for the transportation of different sizes of containers. It can be used repeatedly for a long time and has enough strength.

• No need to change

Container transshipment of goods can be directly loaded in the shipper's warehouse and unloaded in the consignee's warehouse. It is not necessary to take the goods out of the box and replace them when changing vehicles and ships.

• Design Drawing

Before production, we will sent the design drawing to our customer to confirm the detail of the vehicle. We hope we can supply the most suitable product to our customer.

Specifications:

DIMENSIONS
Tare Weight

5300KGS

 Payload 45000KGS
Overall Length 12400mm Overall Width 2480mm
Technical Data
Chassis

Heavy duty and extra durability designed I beam;

Opting for high tensile steel Q345B,

welded by automatic Submerged-Arc processes.

Top Flange 14mm,width 140mm;

Middle Flange 6mm,height 500mm;

Bottom Flange 16mm,width 140mm.
Axle 3axles
Brand name: FUWA
Suspension

Mechanical suspension with 10pcs leaf spring
Spring Leaf spring
King Pin

FUWA brand 2” Bolt-in King Pin
Landing Gear

FUWA brand Two-speed, manual operating, heavy duty landing gear
Wheel Rim

9.0-22.5 steel wheel rim
Twist Lock

12nos. of ISO twist lock for 1x20ft container, 2x20ft container, 1x40ft container
Tyre

12R22.5 tire, 12PCS
Spare Tyre One set of spare tire including a carrier
Braking System

WABCO RE 6 relay valve; T30/30 +T30 Spring brake chamber; 45L air tanks
Painting

Complete Chassis sand blasting to clean rust,

1 coat of anticorrosive prime, 2 coats of final paint
Accessories

One standard tool box, one spare tyre carrier
Gallery
3 Axle Container Delivery Trailer 40 Feet Container Hauler Trailer Enough Strength
