Vacuum Lift CA125M 10 IMPCO Mid Size Engine Mixers
Vacuum Lift CA125M 10 IMPCO Mid Size Engine Mixers
Specifications
Brand Name :
IMPCO
Model Number :
CA125M-10
Certification :
UL
Place of Origin :
USA
MOQ :
24
Price :
Depending on quantity
Payment Terms :
T/T
Supply Ability :
1200pcs per 8weeks
Delivery Time :
8 weeks
Packaging Details :
carton
Product Name :
Mixer
Fuel Type :
LPG Vapor or Natural Gas
Mounting Position :
Vertical
Diaphragm Material :
Hydrin (Standard), Silicone (Optional)
Description

IMPCO Mixer CA125M-10 , A Vacuum Lift Mixer , Airflow Up To 235CFM , LPG / Natural Gas Vapor

DESCRIPTION
The Model 125M-10 is a vacuum lift mixer designed to reduce inlet restrictions in dual fuel installations with airflow requirements up to 235 CFM (111 L/s). In some applications, inlet restrictions cannot be tolerated with a conventional gasoline carburetor as they will cause it to run rich.
The 125M-10 provides an electrically-operated solenoid that directs manifold vacuum to the top diaphragm chamber when gasoline operation is desired. This provides full air valve lift, reducing air inlet restriction to a minimum. The 125M-10 is available with standard type air-gas metering valves and feedback control systems.

SPECIFICATIONS
Fuel Type LPG Vapor or Natural Gas
Inlet Pressure -1.5” w.c. (-0.37 kPa)
Operating Temperature Range -40ºF to +250ºF (-40ºC to 121ºC)
Mounting Position Vertical
Diaphragm Material Hydrin (Standard), Silicone (Optional)
HP/kW Rating 146 hp (175.2 kW) @ 235 CFM (111 L/s) and 2.0” Hg manifold depression

Vacuum Lift CA125M 10 IMPCO Mid Size Engine Mixers

Vacuum Lift CA125M 10 IMPCO Mid Size Engine Mixers

Vacuum Lift CA125M 10 IMPCO Mid Size Engine Mixers
