30000L 35000L 40000L 45000L Aluminium Alloy Milk Tanker Trailer
30000L 35000L 40000L 45000L Aluminium Alloy Milk Tanker Trailer
Specifications
Brand Name :
SUNSKY
Certification :
BV/CCC/CE/DOT/SGS
Place of Origin :
CHINA
MOQ :
1 units
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
500 Units Per Month
Delivery Time :
30 Working Days
Material: :
Aluminum Alloy
Thickness: :
5mm/6mm
Compartment: :
3-6
Capacity: :
30,000L-45,000L
Description

Aluminium Alloy Fuel Tanker Trailer Carry Drink Water Milk Beer

This 45,000L Fuel Tanker Trailer Have Exported to Malawi

Aluminum tanker trailer have a longer life span than carbon steel tank,it can save energy and lighter in tare weight. Even price is higher,but SUNSKY control the cost strictly to ensure you get a best price and quality of aluminum tank from us.

30000L 35000L 40000L 45000L Aluminium Alloy Milk Tanker Trailer

I. Specification

Feature: Carry Drink water, Milk, Beer and chemical liquid
Dimension(L*W*H): 11000*2500*3700mm(30,000L),11700*2500*3750mm(40,000L)
Material: Aluminum Alloy
Compartment: 3-6
Capacity(kgs): 30,000L-45,000L
Tare weight(kgs): 6,000-7,000kgs
Kingpin: The world-famous JOST brand bolt-in/welded type 3.5”/2”
Landing gear: JOST brand two-speed manual operation 19”
Tire size: 11.00R20,11R22.5,12R22.5,315/80R22.5,385/65R22.5
Rim size: 8.25*22.5,9.00*22.5,11.75*22.5
Axle: Original BPW-12T/ FUWA-13T
Leafs spring: Germany type with 12pcs of leafs spring/ Fuwa brand with 8pcs of leafs spring/ Airbag suspension
Brake system: One unit WABCO RE 4 relay valve; four units T30/30 spring brake chamber; two units T30 spring brake chamber; two units reliable local brand 45L air tank; two units reliable local brand standard coppery air-connector.
Manhole: Aluminum alloy ø500mm(20”) manhole with aluminum alloy cover; with breather valve;
Discharge Valve: Aluminum alloy discharge valve with cover
Foot Valve: Pneumatic control DN80 aluminum alloy foot valves
Pneumatic Control system:

1set Pneumatic Control combined switch,

1unit emergency switch
Discharge Hose: 2 units 3”×6M factory PVC hose with quick coupling on both ends
Vapor Recovery & Overfill system: Optional
Fire Extinguisher Carrier: 2 units at the left of rear of tanker, include 2 units 8kg dry powder type fire extinguisher inside
Electric system: One unit of 24V 7-pin ISO standard socket; with brake light, turn light, reverse light, side light, reflector, fog light; one set of 6-pin standard cable
Prime & Topcoat painting: S.A.2.5standard sandblasting ;Zinc-rich & Polyurethane painting

We can build the trailers according to customer’s design and requirement

30000L 35000L 40000L 45000L Aluminium Alloy Milk Tanker Trailer

II. Advantages of aluminum alloy fuel tanker trailer

1. The tank body of SUNSKY aluminum tanker is made of high-strength and wear-resistant high-level aluminum alloy,to ensure the longer life span than ordinary material.

2. Use advanced welding technology and equipment to make sure the high safety and no air leak: Special welding machine to weld the tank body from one side but form smooth, sturdy and uniform welds on both sides.

3. The pipeline system is fitted with reasonable auxiliary blower and anti-wear device to realize smoother unloading process and faster unloading speed.

4. Equipping the famous brand spare parts,such as weichai engine, WBF air compressor that ensure its durability, save your costs on operation and repair.
