Cummins Engine 210 HP 6x4 Refrigerator Van Truck Load 20 T - 25 T
Cummins Engine 210 HP 6x4 Refrigerator Van Truck Load 20 T - 25 T
Specifications
Brand Name :
SUNY
Model Number :
EQ1258
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD 30,000 ~ 45,000 / Unit
Supply Ability :
500 Units / Month
Delivery Time :
15 ~ 20 working days
Packaging Details :
After Waxing by Container , RO-RO , Bulk Freighter
Cargo Body Size :
6900*2300*2100 mm
Cargo Body Material :
FRP inside & outside of the van, polyurethane as the insulation
Cargo body thickness :
80mm
Door :
Single Rear Door , Optional Side Door
Temperature Range :
-18C to 0°C
Engine :
155 kw / 210 hp
Displacement (lit) :
5.900
Number of gears :
8 forward gears & 1 reverse
Brake System :
Air braking
Tire :
11.00-20 & 10+1
Cabin :
Half row, Optional A/C
Description

Cummins Engine 210 HP 6x4 Refrigerated Box Truck Load 20 T - 25 T

Box Volume 20 ~ 30 Cubic

6x4 Dongfeng Refrigerated trucks, Refrigerator Trucks, Frozen Truck , Reefer Van Truck , Cooling Box Truck , Insulation Van Truck (no refrigerator unit)


Thickness: FRP inside & outside of the van, polyurethane as the insulation.

Stainless steel, Q235A steel sheet or aluminum are all optional.
Refrigerators chosen from:
South korean Hanya, HuaSu.
American Thermoking, Carrier.
Chinese Xinfei, Kingbo, etc.


Temperature reaches from -10°C to 0°C
Total capacity: approx. 20000 KG ~ 25000 KG ~ Max .30000 KG
Other spares like hooks, bottom slot, shelves, extra doors, etc. are all optional

Products Technical Specification
Brand-Series Dongfeng
Product Name 6*4 Refrigerated truck
Fuel type Diesel
Emission Standard Euro 3
Cabin Half row, Optional A/C
Chassis standard configuration
Chassis model EQ1258
Whole vehicle main dimensions (mm) Overall dimensions (L×W×H) 9800*2480*3900
Cargo body dimensions (L×W×H) 6900*2300*2100
Wheel base 4350+1300
Front / Rear track base 1680 / 1650
Front / Rear overhang 1245 / 2465
Weight data (kg) G.V.W 25000
Curb weight (chassis) 10395
Max payload 20000 ~ 30000
Whole vehicle
main performance		 Max. speed (km/h) 90
Max. slope of climb (%) 30
Engine Model B210 33
Maximum power 155kw / 210hp
Number of cylinders 6
Displacement (lit) 5.9
Engine Manufacturer Dongfneg Cummins
Gear box Number of gears 8 forward gears & 1 reverse
Axle Front / Rear Load capacity(ton) 5 / 10
Suspension Front / Rear Spring plate 8/13
Steering Wheel left/right hand drive LHD
Brake system Service brake Air braking
Electric device Voltage (V) 24
Tyres & Quantity 11.00-20 & 10+1
Cargo Body Standard Configuration
Cargo Body Size (L×W×H) mm 6900*2300*2100
Cargo Body Material FRP inside & outside of the van, polyurethane as the insulation
Crago body thickness 80mm
Back Door Single door
Side door Optional
Refrigeration systems

Equipped with DT-230

Brand: NIDIAN THERMO (South korean Hanya)
Temperature Range Normal temperature, refrigeration temperature reached -10°C to 0°C
Others

Stainless Steel door frame, Stainless steel corrugated floor,

Mark lamp at the four (4) corners f the body,

Room lamp will be provided inside the cabin.
