FORD Medium Duty Wrecker Tow Truck With 9 Ton Boom And 6 Ton Wheel Llift
FORD Medium Duty Wrecker Tow Truck With 9 Ton Boom And 6 Ton Wheel Llift
FORD Medium Duty Wrecker Tow Truck With 9 Ton Boom And 6 Ton Wheel Llift
FORD Medium Duty Wrecker Tow Truck With 9 Ton Boom And 6 Ton Wheel Llift
FORD Medium Duty Wrecker Tow Truck With 9 Ton Boom And 6 Ton Wheel Llift
FORD Medium Duty Wrecker Tow Truck With 9 Ton Boom And 6 Ton Wheel Llift
FORD Medium Duty Wrecker Tow Truck With 9 Ton Boom And 6 Ton Wheel Llift
FORD Medium Duty Wrecker Tow Truck With 9 Ton Boom And 6 Ton Wheel Llift
FORD Medium Duty Wrecker Tow Truck With 9 Ton Boom And 6 Ton Wheel Llift
FORD Medium Duty Wrecker Tow Truck With 9 Ton Boom And 6 Ton Wheel Llift
FORD Medium Duty Wrecker Tow Truck With 9 Ton Boom And 6 Ton Wheel Llift
FORD Medium Duty Wrecker Tow Truck With 9 Ton Boom And 6 Ton Wheel Llift
Specifications
Brand Name :
SUNY
Model Number :
SYWUIND10
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD 10 , 000 ~ 25 , 000 per unit
Payment Terms :
L / C , D / A , D / P , T / T , Western Union, MoneyGram
Supply Ability :
1000 units per year
Delivery Time :
25 ~ 45 working days after we get the deposit
Packaging Details :
Four units can be loaded into a 40 HQ container.
Boom Rating on first stage :
20 , 000 lbs ( 9 , 071 kg )
Boom Rating on 2nd Stage at 30 degrees :
6 , 000 lbs ( 2 , 722 kg )
Boom Elevation :
39 degrees maximum
Maximum Hook Height :
3962 mm
Winch Capacity :
2 x 12 , 000 lbs ( 5 , 433 kg )
Winch Type :
Worm Gear
Steel Cable :
2 x ½ x 100 '
Special Features :
Free Wheel Manual Tensioner
Description

FORD Medium Duty Wrecker IND 10 Tow Truck With 9 Ton Boom And 6 Ton Wheel Llift

Specifications

IND 10 Ten ton traditional wrecker with independently operated boom and wheel lift . Suitable for towing light duty trucks .

IND 10 Ten ton traditional wrecker with independent boom and wheel lift . Trucks like this have tow millions of vehicles over the years and the IND 10 aims to continue that tradition .

From the gas shock tool box doors to the standard complete wireless controls this wrecker will be the envy of every heavy driver . Keeping you rolling is our priority , so we have gone with all steel hydraulic lines and we have used only the best in cylinders , winches and steel . We have designed the IND 10 to work in any environment and it will fill the gap in your fleet .

As with all our Tow Trucks , customization is the order of the day and we will build your wrecker the way you want it . Do not hesitate to inquire ; standard and customized wreckers are surprisingly inexpensive .

Some optional equipment may be shown .

All ratings are based on structural and design factors only . Vehicle chassis capacity and capabilities can vary significantly , affecting the overall performance and rating of the unit . All chassis specifications are minimums , heavier specifications may be required depending on chassis and equipment weights . Please contact your nearest distributor for additional information .

Our Tow Trucks reserves the right to change , improve or modify products , which may change the specifications , models and features availability at any time without notice and without obligation . Please contact your nearest distributor for additional information .

FORD Medium Duty Wrecker IND 10 Tow Truck With 9 Ton Boom And 6 Ton Wheel Llift

BOOM SPECIFICATIONS

Boom Two Stage
Boom Rating 20 , 000 lbs ( 9 , 071 kg ) on first stage
Boom Rating 6 , 000 lbs ( 2 , 722 kg ) on 2nd Stage at 30 degrees
Boom Elevation 39 degrees maximum
Maximum Hook Height 156 ( 3962 mm )


WINCH SPECIFICATIONS

Winch Capacity 2 x 12 , 000 lbs ( 5 , 433 kg )
Winch Type Worm Gear
Steel Cable 2 x ½ x 100 '
Special Features Free Wheel Manual Tensioner


WHEEL LIFT SPECIFICATIONS

Lift Rating at Full Extension 8000 lbs ( 3628 kg ) on Forks
Fully Retracted Capacity 12 , 000 lbs ( 5443 kg )


VEHICLE RECOMMENDATIONS

Suggested Minimum GVW 18 , 000 lbs ( 11 , 440 kg )
Cab to Axle Distance 60 " to 132 Cab to Rear Axle ( 2134 mm to 3353 mm )

STANDARD FEATURES INCLUDE :

  • Steel body
  • Dual 8 , 000lbs planetary winches
  • Manual spring tensioner
  • Two stage boom
  • Independent underlift
  • Dual manual controls
  • 3 sets of frame forks
  • Frame fork adapters
  • Weather stripping on all tool boxes
  • Sling


OPTIONS AVAILABLE :

  • Custom toolbox configurations
  • In - cab controls
  • Custom paint and graphics
  • Aluminum dress up kit
  • Additional frame forks
  • Custom attachments
  • Heavy duty wheel lift
  • Full installation services
  • Extended warranty
