FAW Jiefang 4 Axles Garbage Container Truck 50000kgs 60000kgs Dump 8X4 Drive
FAW Jiefang 4 Axles Garbage Container Truck 50000kgs 60000kgs Dump 8X4 Drive
FAW Jiefang 4 Axles Garbage Container Truck 50000kgs 60000kgs Dump 8X4 Drive
FAW Jiefang 4 Axles Garbage Container Truck 50000kgs 60000kgs Dump 8X4 Drive
FAW Jiefang 4 Axles Garbage Container Truck 50000kgs 60000kgs Dump 8X4 Drive
FAW Jiefang 4 Axles Garbage Container Truck 50000kgs 60000kgs Dump 8X4 Drive
FAW Jiefang 4 Axles Garbage Container Truck 50000kgs 60000kgs Dump 8X4 Drive
FAW Jiefang 4 Axles Garbage Container Truck 50000kgs 60000kgs Dump 8X4 Drive
Specifications
Brand Name :
SUNY
Model Number :
SY5126ZXLJ
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD40000-USD65000
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
200 set per month
Delivery Time :
15 - 25 working days
Packaging Details :
Ro-ro sihpping / Bulk cargo shipping / Container shipping / SKD / CKD / etc
Chassis brand/model :
FAW
Chassis no. :
CA3250
Garbage van capacity :
50ton 60ton
Engine :
CA6DM2-37E4U2
Drive :
8x4
Wheel base :
2100+4300+1350mm
Horse power :
350 hp
Function :
transport and unload the heavy garbage
Tank material :
Q235
Dimension :
11350*2500*3680 mm
Description

FAW Jiefang 4 Axles 50000kgs 60000kgs Dump Garbage Trucks 8X4 Drive

Description&Applications:

Garbage truck is a kind ofthe urban sanitation special vehicle which is used to highly collecting,transporting and unloading garbage and could avoid leaking--- secondary pollution in the collecting and transiting process.It is the ideal urban sanitation equipment. I can carry big and heavy garbage such as construction garbage,

Competitive Advantage:

1- competitive price-----based on same product, our price is most competitive

2- powful R & D capabilities------we can design and produce the truck according to different trash cans of different countries so that it can be fit for the different countries’ demand.

3- strict quality control----stable quality for each truck

4- best service-----we cherish each customer and opportunity.

Specifications:

FAW Jiefang 4 Axles 50000kgs 60000kgs Dump Garbage Trucks 8X4 Drive

Products Technical Specification
Type 8*4 Dump truck
Brand FAW
Cab J6P,Half row,With A/C,sleeper
Vehicle Description
Overall dimensions(mm) 11350*2500*3680
G.V.W (kg) 31000
Curb weight(vehicle) (kg) 14845
Loading capacity (kg) 45000kgs 50000kgs 55000kgs 60000kgs
Max speed (Km/h) 85
Engine
Engine model CA6DM2-37E4U2
Maximum power 267kw / 370hp
Displacement (lit) 11.05
Engine Manufacturer FAW
Chassis Description
Chassis Model CA3310
Wheel base 2100+4300+1350
F/R track base(mm) 2022/1830
F/R overhang(mm) 1470/1090
Approach/Departure angle(°) 24/45
Spring plate 10/10/12
Front axle / rear axle 300
Type of fuel Diesel
Transmission CA12TAX190M ,12-Speed
Brake System Air braking
Operation control system Power steering
Electric system 24V
Tire specification 12.00R 20
Up-parts Description
Van dimensions(mm) 8300/8500*2300*1500/1800
Van description

Equipped with material of carbon steel,

side 6mm thickness; bottom 8mm thickness

Equipped with front hydraulic ram, single door.
Optional Configuration
Cargo body thickness,side door,and HYVA brands hydraulic cylinder,etc.

FAW Jiefang 4 Axles Garbage Container Truck 50000kgs 60000kgs Dump 8X4 Drive
