ISUZU 4x2 Fuel Oil Tank Trailer Carbon Steel 4000 L Refuel Tanker Truck
ISUZU 4x2 Fuel Oil Tank Trailer Carbon Steel 4000 L Refuel Tanker Truck
ISUZU 4x2 Fuel Oil Tank Trailer Carbon Steel 4000 L Refuel Tanker Truck
ISUZU 4x2 Fuel Oil Tank Trailer Carbon Steel 4000 L Refuel Tanker Truck
ISUZU 4x2 Fuel Oil Tank Trailer Carbon Steel 4000 L Refuel Tanker Truck
ISUZU 4x2 Fuel Oil Tank Trailer Carbon Steel 4000 L Refuel Tanker Truck
Specifications
Brand Name :
SUNY
Model Number :
SY5040GJYE
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD 25,200~ 35,000 FOB Shanghai
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 units/per year
Delivery Time :
25~35 days after we get the deposit
Packaging Details :
Ro-ro shipping / Bulk cargo shipping / Container shipping / SKD / CKD / etc.
Vehicle type :
Refuel Tanker Truck
Engine model :
120 hp, EURO 4 emission
Chassis model :
QL1040
Tank material :
carbon steel
truck wheel base :
3360 mm
Tyre :
7.00-16, 6+1 pieces
Oil tank volume :
4000 L = 4 m3
Type of fuel :
Diesel / Gasoline
Description

ISUZU 4x2 Fuel Tanker Truck Trailer Carbon Steel 4000 L Refuel Tanker Truck

Description:


Our refuel oil tank truck or trailer are optional Q345, SUS304, AA5083/5454 tank material.


We are main fuel tanker turck manufacturer, specialized in making customized fuel tanker part, oil tank truck, chemical tanker truck, tanker trailer, tanker container, refuel station container.

Divided by chassis brand:Changan fuel tank truck, Wuling fuel tank truck, Dongfeng serials fuel tank truck, Jiefang serials fuel tank truck, Auman serials fuel tank truck, Howo serials fuel tank truck, Benz serials fuel tank truck, Sinotruck serials fuel tank truck, ISUZU serials fuel tank truck, JAC serials fuel tank truck, CAMC serials fuel tank truck, Shaanxi auto serials fuel tank truck, Steyr serials fuel tank truck.

Competitive Advantage:


Fuel tank body can be divided into several compartments with wave resistant board inside to reduce liquid shock and increase tank body strength and stability.


Fuel pump self-suction, gear pump, chemical agent pump, numeral control refueler, the funtion for loading and discharge through are not throught gauge are available. Rear tank has 2-3 discharge vent.
Divided by gross weight: Mini fuel tank truck, light fuel tank truck, middle sizes fuel tank truck, heavy duty fuel tank truck.


Divided by wheel:single axle fuel tank truck, double axles fuel tank truck, 4X4 fuel tank truck, 8X4 fuel tank truck, fuel tank semi-trailer.

ISUZU 4x2 Fuel Tanker Truck Trailer Carbon Steel 4000 L Refuel Tanker Truck

TRUCK SPECIFICATION
Product Model SY5040GJYE ISUZU 4*2 refuel tank truck
Overall dimensions (L*W*H)

5950*1880*2280 mm
G.V.W Approx 9400 kg
Net weight Approx 4225 kg
load Approx 8000 kg
Approach/Departure angle 21/12 °
F/R suspension 1180/2020 mm
Axle load 2480/4700 kg
Max speed 95 km/h
Allowable passengers 2+1
Cab type Flat top. one row and a half. Turning cab. Red metallic painting
Cab inner with air condition and warm air
CHASSIS SPECIFICATION
Chassis model QL1040
No. of axle 2
Wheel base 3360 mm
No. of tire & specification 7.00-16.(optional 7.00R16)
No. of leaf spring pieces 8/6+5
F/R tread 1504/1425 mm
Tractions 4*2
Braking system Hydraulic braking.
Operation control system Power steering
Electric system 24 V
ENGINE SPECIFICATION
Engine model (emission standard) 4KH1-TCG40 (EURO 4, ISUZU engine)
Manufacturer QINGLIN ISUZU Engine
Fuel type Diesel
No. of cylinder 6
Cylinder arrangement form In-line engine
House power 120 hp / 88 kw
Exhaust 2771 ml
Max torque 640 N.m
Max torque speed 1500 r/min
Rated power speed 2500 RPM
Engine type In line 6-cylinder with electric preheating devices and high power 6.6 kw starter, a radical improvement in the engine cold start.
Intake Forms Turbocharged
TRANSMISSION
Transmission model ISUZU MSB Transmission type Manual
No. of reverse gear 1 No. of forward gears stalls 5
FUEL TANK TRUCK EQUIPMENTS AND FUNCTIONS
Tank capacity 4000 L ( 4 m³)
Tank dimensions (L*W*H) 3400*1680*1130 mm
Tank material Q235A (optional: stainless steel / aluminum / plastic lining / rotational modeling)
Tank shape Square round / Cylinder / Ellipse
Manhole DN500 (optional few manhole, by the branch warehouse, EURO standard)
Pump Equipped with the specific pump to suck and discharge the oil automatically.
Refuel tank truck equipments

Computer control injector / Fuel hose / Fuel gun / Flow meter.

 Tank can be separated to several unattached small tanks to fill different oil.

This fuel truck is one sample, If it can not you’re your requirement, Please contact S-K-Y-P-E Zengertruck
