Specifications
Brand Name :
SUNY
Model Number :
CLW5102GJYB3
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD 18,000~ 25,000 FOB Shanghai
Payment Terms :
Western Union, MoneyGram, D/A, D/P, L/C, T/T
Supply Ability :
1000 units/per year
Delivery Time :
25~35 days after we get the deposit
Packaging Details :
Ro-ro sihpping / Bulk cargo shipping / Container shipping / SKD / CKD / etc
Drive form :
4*2
Transport medium :
optional oil, diesel, crude oil and so on
Type of fuel :
diesel
Max speed :
90km/h
Horsepower :
138hp
Engine model :
YZ4DB1-30
Cab :
One row
Color :
opptional
Description

Foton Oil Tank Truck 4*2 Fuel Tank Truck 138 HP carbon steel Tanker Truck

Description & Applications:

1. Oil tank truck, mobile oil tank truck, diesel or petrol transporting truck, stainless steel oil tank truck
2. Oil tanker truck, fuel tanker truck, petroleum tanker truck, which are mainly used for transporting oil.
some oil tanker truck could be also a refueling tank truck, with refueling device.
3. Our company also produce the oil tank trailer,the manufactuere standard could be according to European standard.

4. Tank material: carbon steel, stainless steel, aluminum alloy material tank for choose.

5. You can choose to install heating pipes, insulation layer. The Insulation material is generally 50-100 mm

Thickness, insulation can be used rock wool, glass wool, polyurethane foam, aluminum silicate. The cladding

6. At the end or side of tank, it can be installed 1-3 self-flow valve.

7. According to users’ needs, the tank can be designed as a single compartment or several compartments to contain different oils.

Foton Oil Tank Truck 4*2 Fuel Tank Truck 138 HP carbon steel Tanker Truck

Vehicle Description

 Vehicle brand Foton
Vehicle type Oil Tank Truck
Drive form 4*2
Overall dimension (mm) 7000x2250x2600
G.V.W(kg) 10495
Load capacity (kg) 5210
Curb weight (kg) 5090

Chassis Description

 Chassis brand Foton
Axle load (kg) 4200/6295
F/R overhang (mm) 1120/2080
Approach/Departure angle ( ° ) 15/11
Tread (mm) 2040 / 1860
Wheelbase (mm) 3800
Spring plate 9/11+7
Tyre size & quantity

8.25-16,8.25R16,8.25-20,8.25R20
Cab One and half row

Engine Description

 Engine model YZ4DB1-30
Displacement (ml) 4087
Max power (kw) 80
Horsepower (hp) 138
Max speed (km/h) 80
Emission standard Euro 4
Type of fuel Diesel

Tank Description

 Tank volume (m³) 8
Transport medium Gasoline
Density (kg/m³) 700
Tank size (mm) 4000x2000x1350

Foton Oil Tank Truck 4*2 Fuel Tank Truck 138 HP carbon steel Tanker TruckFoton Oil Tank Truck 4*2 Fuel Tank Truck 138 HP carbon steel Tanker TruckFoton Oil Tank Truck 4*2 Fuel Tank Truck 138 HP carbon steel Tanker Truck
