JAC 6000 L 141hp Vacuum Tank Truck Water Cleaning Tank Truck
JAC 6000 L 141hp Vacuum Tank Truck Water Cleaning Tank Truck
JAC 6000 L 141hp Vacuum Tank Truck Water Cleaning Tank Truck
JAC 6000 L 141hp Vacuum Tank Truck Water Cleaning Tank Truck
JAC 6000 L 141hp Vacuum Tank Truck Water Cleaning Tank Truck
JAC 6000 L 141hp Vacuum Tank Truck Water Cleaning Tank Truck
JAC 6000 L 141hp Vacuum Tank Truck Water Cleaning Tank Truck
JAC 6000 L 141hp Vacuum Tank Truck Water Cleaning Tank Truck
JAC 6000 L 141hp Vacuum Tank Truck Water Cleaning Tank Truck
JAC 6000 L 141hp Vacuum Tank Truck Water Cleaning Tank Truck
JAC 6000 L 141hp Vacuum Tank Truck Water Cleaning Tank Truck
JAC 6000 L 141hp Vacuum Tank Truck Water Cleaning Tank Truck
JAC 6000 L 141hp Vacuum Tank Truck Water Cleaning Tank Truck
JAC 6000 L 141hp Vacuum Tank Truck Water Cleaning Tank Truck
Specifications
Brand Name :
SUNY
Model Number :
HFC1081K2F
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD20000-28000 / Set
Supply Ability :
50 sets per month
Delivery Time :
25 days after receiving deposits
Packaging Details :
bulk,ro-ro,container
Tank capacity :
6000 L
Tank material :
Q235
Engine model :
ISF3.8s4141
Sewage sludge Tank Dimension :
φ1400×2150 mm
Water Tank Dimension :
φ1400×2000 mm
Tire specification :
8.25-16 14PR
Wheel base :
3800 mm
Engine Power :
141 hp
Description

JAC 6000 L 141hp Vacuum Tank Truck Water Cleaning Tank Truck

Applications:

1. Dredging and cleaning of sewer pipeline and gutter.

2. Cleaning of building outer wall.

3. Other cleaning work.

4. Street flushing, chemical and water-spraying

5. Bring underground cables and pipes to the surface

Competitive Advantage:

1. Equipped with special vacuum pump, Equipped with power take off, transmission shaft, high pressure sewage tank, pipe network, sewage pipe for observing and cleanout equipment, Time for full suction<5min

2. The Sewage Suction Trucks, special section, taking the force transmission device by rotary vane pumps, vacuum pump, ( with domestic leading technology big suction ) oil and gas separation device, hydrosphere separator, vacuum pressure gauge, pressure vessel, pipe system composition, and equipped with hand-washing facilities and visual dung tube.

3. The tanks bulbar and the horizontal sextant angle are greater than the material rest angle, ensuring the discharging speed.

4. The diesel engine ( air compressor unit ), providing compressed air.

Specifications:

Vehicle Description

Vehicle model

Sewage suction truck

Overall dimensions ( mm )

6860*2040*2800

GVW ( kg )

Appro×8495

Fact loading capacity ( L )

6000

Mass in working order ( kg )

Appro×5300

Max. Speed ( km/h )

90

Chassis Description

Chassis Model

HFC1081K2F

Cab

Standard cabin with left hand drive

Color

Optional

Allowable person in cab

2/3

Wheel base ( mm )

3800

Front/Rear track base ( mm )

1880/1800

Front/Rear overhang ( mm )

1850/2370

Number of axles

2

Axle

Front axle

3060

Rear axle

5435

Traction system

4*2

Operation control system

Power steering

Braking system

Full air

Electric system

24V

Transmission

5speed

Spring plate

9/6+6

Tire specification

8.25-16 14PR

Tire quantity

6+1

Engine Description

Engine model

ISF3.8s4141

Emission standard

Euro 4

Exhaust/output

3760 ml/105 kw

Horse power

141hp

Up-parts Description

Sewage sludge Tank Dimension ( mm )

φ1400×2150

Water Tank Dimension ( mm )

φ1400×2000

Standard Equipment

Equipped with high-power vacuum suction sewage pump.

Equipped with lifting function, and double hydraulic cylinder, rear cover can hydraulic opening with self-flowing valve.

Equipped with power take off, transmission shaft, pipe network, sewage pipe for observing and cleanout equipment.

Working Condition:

1,Altitude: 0-4500 m

2,Temperature: -350 C~+450 C

3,Relative humidity: 80%

4,Wind force: ≤8 degree

JAC 6000 L 141hp Vacuum Tank Truck Water Cleaning Tank Truck
