FOTON FORLAND Vacuum Cleaning Tank Truck Two Axles Professional
FOTON FORLAND Vacuum Cleaning Tank Truck Two Axles Professional
FOTON FORLAND Vacuum Cleaning Tank Truck Two Axles Professional
FOTON FORLAND Vacuum Cleaning Tank Truck Two Axles Professional
FOTON FORLAND Vacuum Cleaning Tank Truck Two Axles Professional
FOTON FORLAND Vacuum Cleaning Tank Truck Two Axles Professional
FOTON FORLAND Vacuum Cleaning Tank Truck Two Axles Professional
FOTON FORLAND Vacuum Cleaning Tank Truck Two Axles Professional
FOTON FORLAND Vacuum Cleaning Tank Truck Two Axles Professional
FOTON FORLAND Vacuum Cleaning Tank Truck Two Axles Professional
Specifications
Brand Name :
SUNY
Model Number :
BJ1083VEJEA-1
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD18000-20000 / Set
Supply Ability :
50 sets per month
Delivery Time :
25 days after receiving deposits
Packaging Details :
bulk,ro-ro,container
Tank capacity :
6000 L
Tank material :
Q235
Tank shape :
Elliptic cylinder
Whole tank dimension :
3780x1700x1280 mm
Whole truck dimension :
5990x2020x2680 mm
Tire specification :
7.50-16
Wheel base :
3600 mm
Engine Power :
110 hp
Description

FOTON FORLAND Vacuum Cleaning Tank Truck Two Axles Professional

Description:

This truck is mainly used for urban water wells and the examination of the wells. Help sucking, loading and unloading the sediment in various kinds of channels in the sludge, sewage or petrochemical sewage pool.

Applications:

Rinsing underground sewage pipes, the collection and transportation of sludge and city life waste and building operations such as muddy water in liquid waste and other functions.

Competitive Advantage:

1. Equipped with special vacuum pump, power take off, transmission shaft, high pressure sewage tank, pipe network, sewage pipe for observing and cleanout equipment. Time for full suction < 5min

2. The Sewage Suction Trucks, special section, taking the force transmission device by rotary vane pumps, vacuum pump, ( with domestic leading technology big suction ) oil and gas separation device, hydrosphere separator, vacuum pressure gauge, pressure vessel, pipe system composition, and equipped with hand-washing facilities and visual dung tube.

3. The tanks bulbar and the horizontal sextant angle are greater than the material rest angle, ensuring the discharging speed.

4. The diesel engine ( air compressor unit ), providing compressed air.

Specifications:

Vehicle Description

Vehicle model

Sewage suction truck

Overall dimensions ( mm )

5990*2020*2680

GVW ( kg )

Appro×8275

Fact loading capacity ( L )

6000

Mass in working order ( kg )

Appro×4080

Max. Speed ( km/ h )

90

Chassis Description

Chassis Model

BJ1083VEJEA-1

Cab

Standard cabin with Left hand drive

Color

Optional

Allowable person in cab

2/3

Wheel base ( mm )

3600

Front/Rear track base ( mm )

1550/1530

Front/Rear overhang ( mm )

1110/1520

Number of axles

2

Axle

Front axle

2810

Rear axle

5465

Traction system

4*2

Operation control system

Power steering

Braking system

Full air

Electric system

24V

Transmission

5speed

Spring plate

10/9+6

Tire specification

7.50-16

Tire quantity

6+1

Engine Description

Engine manufacture

CHINA YUNEI ENGINE CO., LTD

Engine model

YN33CR-3

Emission standard

Euro 3

Exhaust/ output

3298/79

Horse power

110

Up-parts Description

Tank Dimension ( mm )

3780x1700x1280

Standard Equipment

Equipped with high-power vacuum suction sewage pump.

Equipped with lifting function, and double hydraulic cylinder, rear cover can hydraulic opening with self-flowing valve.

Equipped with power take off, transmission shaft, pipe network, sewage pipe for observing and cleanout equipment.

Working Condition:

1,Altitude: 0-4500 m

2,Temperature: -350 C~+450 C

3,Relative humidity: 80%

4,Wind force: ≤8 degree
