Specifications
Brand Name :
SUNY
Model Number :
SY5151XFIZ
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD65000 /set- USD85000/set
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
200 set per month
Delivery Time :
15-25 working days
Packaging Details :
Ro-ro sihpping / Bulk cargo shipping / Container shipping / SKD / CKD / etc
Chassis brand/ model :
ISUZU/ CXA34T
Water tank capacity :
9000L
Tank material :
Q235
Dimension :
10210*2490*3560 mm
Engine :
6HK1-TC
Drive :
6x4
Wheel base :
5100+ 1300 mm
Description

ISUZU 9000 L 6x4 Water Tank Fire Fighting Truck 3 Axle 260 Hp Double Row Cab


Description & application:
1- Water tank fire truck equipped with water storage tank, fire pumps, fire fighting water cannon, and other fire equipment to put out the fire. It also can be absorb water directly and supply water to other fire vehicle, equipment or water supply shortage region. It is suitable for general fire put out.
2- Water and foam fire truck water tank equipped with fire pump and foam mixed system, bubble gun, cannon, and etc., can spray water and foam mixture to put out the fire during extigushing. It is specially suitalbe in petrochemical industry, power plants and valuable equipment instruments, it is the necessaary fire truck for petrochemical enterprises, oil terminals, airport and city fire extigushing field.
3- There are Dry powder fire truck and Ladder fire truck optional

Competitive Advantage:
1- powful R & D capabilities ---- we can design and produce the truck according to different fire equipment of different countries so that it can be fit for different countries’ demand.
2- strict quality control ---- stable quality for each truck
3- competitive price ----- based on same product, our price is most competitive
4- best service ----- we cherish each customer and opportunity.

Specifications:ISUZU 9000 L 6x4 Water Tank Fire Fighting Truck 3 Axle 260 Hp Double Row Cab

Product

Fire truck

Vehicle

description

Overall dimensions ( mm )

10210*2490*3560

GVW ( kg )

24500

Mass in working order ( kg )

13000

Rated loading capacity ( kg )

11050

chassis

parameters

Chassis mod

CXA34T

Fact cubage ( L )

9000

Water tanker dimension

3010*2300*1300

Approach/Departure angle ( ° )

26/14

F/R overhang ( mm )

1335/2420

Wheel base ( mm )

5100+1300

F/R track base ( mm )

1960/1855/1855

Traction system

6*4

Number of axles

3

F/R axle-load ( Kg )

6500/18000

Spring plate

9/10

Braking system

Air braking

Tire specification

11.00-20

Number of tires

10+1

Electric system

24v

Allowable passengers in cab

2+4

Air-conditioner

optional

Engine

Engine model

6HK1-TC

Type of fuel

Diesel

Exhaust(ml)

7790

Rated Power ( kw )

191

Horse power

260

Operation control system

Steering wheel

Max speed (km / h )

85

Manufacturer

Qingling Motors Co., LTD

Emission standard

EURO 3

Equipment

Middle and low pressure pump :CB20.10 / 30.60

Flow:middle pressure 30 L / S low pressure 60 L / S

Pressure: middle pressure 2.0 MPa low pressure 1.0 MPa

PL48 Fire Pump Flow: 48 L / S

Pressure: 1.0～1.2 MPa

Fire distance ( water ) : ≥ 65 m

Production cycle

15-20 days

Warranty

12 month, from the date of supply
