Long Cab 6 Ton Swing Off Garbage Trucks With LHD Steering Wheel
Long Cab 6 Ton Swing Off Garbage Trucks With LHD Steering Wheel
Long Cab 6 Ton Swing Off Garbage Trucks With LHD Steering Wheel
Long Cab 6 Ton Swing Off Garbage Trucks With LHD Steering Wheel
Long Cab 6 Ton Swing Off Garbage Trucks With LHD Steering Wheel
Long Cab 6 Ton Swing Off Garbage Trucks With LHD Steering Wheel
Long Cab 6 Ton Swing Off Garbage Trucks With LHD Steering Wheel
Long Cab 6 Ton Swing Off Garbage Trucks With LHD Steering Wheel
Long Cab 6 Ton Swing Off Garbage Trucks With LHD Steering Wheel
Long Cab 6 Ton Swing Off Garbage Trucks With LHD Steering Wheel
Specifications
Brand Name :
SUNY
Model Number :
SY140ZBS
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD 17,000~ 28,000 FOB Shanghai
Supply Ability :
1000 units per year
Packaging Details :
Ro-ro shipping / Bulk cargo shipping / Container shipping / SKD / CKD / etc
Garbage Container capacity :
6M3
Garbage Container material :
side 3 mm, bottom 4mm
Garbage Container shape :
aqusre shape, boat shap, bucket shape
Garbage Containers :
one truck to many garbage containers
Engine emission standard :
euro 2, euro 3, euro 4, euro 5
Whole truck dimension :
7185 * 2470 * 3300 mm
Truck chassis wheelbase :
3950 mm
Description

Long Cab 6 Ton Swing Off Garbage Truck, 6M3 Refuse Collector Truck For Sale

1. chassis: Dongfeng 140 long cab swing off garbage truck;

2. capacity: 6 M3 or 6 ton;

3. tire: 9.00-20;

4. engine: 140 hp, Euro III emission standard.

5. one truck to several garbage containers.

Description:

The garbage truck is widely used in sanitation & municipal, industrial enterprises and residential area. The truck has several garbage tanks to avoid pollution during transporting process. The modified part can be separated from chassis, so it is easy to maintain and the mobility & readability of the truck are kept.
If you have special demand of garbage truck, please contact with us. We may design and modify it for you. We also can add power steering and A/C for you.

Specifications:

Items

Descriptions

Specifications

General

Vehicle name

140 long cab Swing off garbage truck

The total mass ( kg )

10490

Curb weight ( kg )

5795

Payload weight ( kg )

4500

Overall dimensions ( mm )

7185 * 2470 *3300

Top speed ( km / h )

95

Driving cab capacity

3 person

Garbage box capacity

6m³

Engine

Fuel type

Diesel

Engine model

YC4E140-33

Engine power ( kw )

103

Displacement ( ml )

4257

Emission standard

Euro 3

Chassis

Chassis model

EQ1110FLJ8

Steering wheel

LHD

Axle

2

Tire specification

9.00-20

Wheelbase (mm)

3950

Wheel tread(mm)

1900 / 1800

Front/rear suspension(mm)

1250 / 2180

Approach/departure angle(°)

33 / 12

Spring leaf number

8 / 11 + 8

Equipment

Protective part material: Q235A carbon steel.

Rear protective section size: 150 * 50 mm, with 520 mm terrain clearance.

Equipped with tachograph with satellite positioning function.

Structure& Function

Container Capacity ( m3 ) : 6

Lifting arm circumference radius ( mm ) : 2400

Filling Circulation Time ( s ): 20-25

Unloading bucket hoisting time ( s ) : 30

The hydraulic system working pressure ( Mpa ) :16

Long Cab 6 Ton Swing Off Garbage Trucks With LHD Steering Wheel
