Suction System Specification

Tank

Tank Capacity ( L )

5000

Tank Material

Q235A carbon steel ( Stainless steel is optional )

Tank Shape

Elliptical shape

Tank Size ( length * macro axis*mini axis )( mm )

3800*1600*1100

Vacuum pump

Model

China famous WEILONG ( Optional )

Max Vertical Suction ( m )

≥ 8

Absolute Working Pressure ( pa )

8500

Rated Speed

500

Rated Pumping Speed ( L/ s )

98

Pump inlet diameter ( mm )

50

Container Filling Time ( s )

≤ 5

Container Emptying time ( s )

≤ 5

Chassis Specification

Model

DFA1070SJ20D5

Engine

Model

CY4102-CE4D

Type

Four-cylinder, water-cooled, mechanical injection

Rated power ( Hp )

112

Transmission

Model

DONGFENG

Type

5 Forward & 1 Reverse Speed

Travelling

Drive Model

4 x 2

Steering Wheel Position

Left hand drive

Max. Travelling speed

95

Dimension

Overall Size ( mm )

5990 x 1980 x 2400

Tire Size

7.00-16

Wheel Base ( mm )

3300

Weight

Curb Weight ( kg )

3665

Payload Capacity ( kg )

3500

Super Tank: Head and the tank made by a molding, thickening, anti-high-pressure.

Sub frame: Full sub-frame with flexible mounting fixed to the truck chassis by horse bolts. Sub-frame and chassis medium with wooden plates.

Vacuum System: Liquid ring vacuum pump, is driven from the PTO on the gearbox, provides high airflows along with high vacuum levels for removing debris above or below liquid surfaces.

Tank Mounting: The truck will be equipped at our expense with a sub frame according to truck manufacturer’s prescriptions.

Painting: All steel parts are sand blasted before painting. One anti-corrosion and zinc-rich primer and final painting at customer’s choice of colour.All steel parts are steel blasted before painting. Paint markers according to customer’s demand.

Suitable for the transport of non-hazardous waste products and built according to the design rules for vacuum operated waste tankers.
