Skeleton 30 Ton Two Axle Flatbed Semi Trailer 40 Foot Flatbed Trailer
Skeleton 30 Ton Two Axle Flatbed Semi Trailer 40 Foot Flatbed Trailer
Skeleton 30 Ton Two Axle Flatbed Semi Trailer 40 Foot Flatbed Trailer
Skeleton 30 Ton Two Axle Flatbed Semi Trailer 40 Foot Flatbed Trailer
Skeleton 30 Ton Two Axle Flatbed Semi Trailer 40 Foot Flatbed Trailer
Skeleton 30 Ton Two Axle Flatbed Semi Trailer 40 Foot Flatbed Trailer
Skeleton 30 Ton Two Axle Flatbed Semi Trailer 40 Foot Flatbed Trailer
Skeleton 30 Ton Two Axle Flatbed Semi Trailer 40 Foot Flatbed Trailer
Specifications
Brand Name :
SUNY
Model Number :
SY9203GJ
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD 18,000 ~ 25,000 FOB
Payment Terms :
T/T, L/C
Supply Ability :
1000 units / per year
Delivery Time :
20 ~ 25 working days
Packaging Details :
After Waxing by Container, RO-RO, Bulk Freighter
Trailer Material :
Q235 & Q345
Overall Dimensions :
12390 * 2480 *1 490 mm
Trailer Load :
30 tons
Axles :
3 axles 13 t Fuwa
Suspension :
Mechanical Suspension
Brake System :
WABCO Brand
Outrigger :
28 t Fuwa Optional Jost
Tire :
12.00R22.5 * 8pcs
Description

2 Axle Skeleton Container Semi Trailer 40 FT ISO Container Transport Frame Trailer Load 30 Tons

Description:

Semi trailer is our company's main product. We configure Grid type semi trailer ,low bed semi trailer, container semi trailer, flat bed semi trailer, LPG tank semi trailer, fuel tank semi trailer, water tanker semi trailer, fecal suction semi trailer, sewage suction semi trailer, compactor garbage semi trailer, van semi trailer, box semi trailer, water tank semi trailer, bitumen semi trailer, bulk cement semi trailer, dump semi trailer, chemical tank semi trailer and etc. We produce tank semi trailer with plastic lining, aluminum tank, aluminum alloy tank, rotational molding, carbon steel, stainless steel, production according to the customer's requirement.

Specification:

ISO 20FT / 40FT / 45FT Transportation Container Skeleton Container Transport Semi Trailer

( skeleton container trailer material: carbon steel)

( skeleton container trailer opting 20FT, 30FT, 40FT, or with lift cylinder unloading )

( skeleton container trailer axle opting: 1, 2, 3, 4 axle & lift axle semi trailer / full trailer )

Skeleton Container Semi Trailer Specifications

( SY9203GJ 2 axle skeletal container semi trailer for 2 sets 20 ft or 1 set 40 ft ISO container )

Overall dimensions (L*W*H)

12390 * 2480 *1 490 mm

(3525 mm height with hydraulic tipping cylinder)

Design Loading

30000 kg = 50 tons ( for 2 set 20 ft or 1 set 40ft container )

GVW

Approx 35500 kg

Mass in working order

Approx 5500 kg

Axle specification

13 ton × 2 pcs (FUWA axle) optional: FUWA 15 T, BPW 12T

Axle load

-/ 18000 kg (2 axles)

Wheel base

8610+1310 mm

Front / Rear track base

- 1840 / 1840 mm

Suspension system

Mechanical suspension, opting air suspension.

Front / Rear suspension

- / 1350 mm

Approach / Departure angle

- / 26 °

Tire specification

12.00R22.5 × 8 pcs ( vacuum tires ) opting single tire type

Spring few films

13 × 90-10 (optional: -/8/8,- /10/10)

King pin

50 # China brand kingpin, opting 90 # / JOST.

Landing leg

28T load landing leg, optional JOST.

Braking system

Optional: China brand 4S/2M ABS / WABCO ABS

Twist Lock

8 No. Of ISO twist lock for 2 sets 20 ft / 1 set 40 ft container

Accessories

Mudguards

PVC Mudguards

Side protection

Nil.

Fire extinguishers carriers

2 pcs

Spare tire carrier

1 pc

Container locker

8 sets

Tool box

1 tool box
