3 Axle 100 Ton Low Bed Semi Trailer Heavy Duty Flatbed Trailer With Manual Ramp
3 Axle 100 Ton Low Bed Semi Trailer Heavy Duty Flatbed Trailer With Manual Ramp
3 Axle 100 Ton Low Bed Semi Trailer Heavy Duty Flatbed Trailer With Manual Ramp
3 Axle 100 Ton Low Bed Semi Trailer Heavy Duty Flatbed Trailer With Manual Ramp
3 Axle 100 Ton Low Bed Semi Trailer Heavy Duty Flatbed Trailer With Manual Ramp
3 Axle 100 Ton Low Bed Semi Trailer Heavy Duty Flatbed Trailer With Manual Ramp
3 Axle 100 Ton Low Bed Semi Trailer Heavy Duty Flatbed Trailer With Manual Ramp
3 Axle 100 Ton Low Bed Semi Trailer Heavy Duty Flatbed Trailer With Manual Ramp
3 Axle 100 Ton Low Bed Semi Trailer Heavy Duty Flatbed Trailer With Manual Ramp
3 Axle 100 Ton Low Bed Semi Trailer Heavy Duty Flatbed Trailer With Manual Ramp
Specifications
Brand Name :
SUNY
Model Number :
SY9310DPB
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD 37,000~ 55,000 FOB
Payment Terms :
T/T, L/C, Western Union, Paypal, MoneyGram,
Supply Ability :
1000 units / per year
Delivery Time :
25 - 35 working days
Packaging Details :
After Waxing by Container, RO-RO, Bulk Freighter
Trailer Material :
Q235 and Q345
Trailer Load Capacity :
100 Tons
Trailer Axle :
3 pcs * 16 T FUWA
Trailer Leg :
28 T FUWA Optional
Trailer Suspension :
Mechanical Suspension
Trailer Tire :
12.00R20 * 12 pcs
Trailer Brake System :
WABCO
Trailer Ladder :
Mechanical or Hydraulic
Description

100 Tons Low Bed Semi Trailer 3 Axle Heavy Duty Low Flat Bed Trailer With Manual Ramp

Descriptions:

Semi trailer is our company's main product. We configure Grid type semi trailer ,low bed semi trailer, container semi trailer, flat bed semi trailer, LPG tank semi trailer, fuel tank semi trailer, water tanker semi trailer, fecal suction semi trailer, sewage suction semi trailer, compactor garbage semi trailer, van semi trailer, box semi trailer, water tank semi trailer, bitumen semi trailer, bulk cement semi trailer, dump semi trailer, chemical tank semi trailer and etc. We produce tank semi trailer with plastic lining, aluminum tank, aluminum alloy tank, rotational molding, carbon steel, stainless steel, production according to the customer's requirement.

Sepcification:

100 tons Low Flat Bed Semi Trailer

( low bed trailer material: carbon steel )

(low bed trailer capacity: from 30 ton to 100 ton. Dimensions optional.)

(low bed trailer ramp opting : spring ramp / hydraulic ramp )

(low bed trailer axle opting: 1, 2, 3, 4 axle )

Low Bed Semi Trailer Specifications

( SY9310DPB 3 axle low bed semi trailer )

Overall dimensions (L*W*H)

12390 * 3000 * 3180 mm

(with rear ramp height), 1750 mm height without ramp height

Design Loading

100000 kg = 100 tons

GVW

Approx 113800 kg

Mass in working order

Approx 13800 kg

Floor deck

5 mm check plate

Axle specification

16 T × 3 pcs ( FUWA axle ) optional: BPW

Wheel base

8580 + 1310 + 1310 mm

Front / Rear track base

- / 2180 / 2180 / 2180 mm

Suspension system

Mechanical suspension

Front / Rear suspension

-/ 1400 mm

Approach / Departure angle

- / 16 °

Tire specification

12.00R20 × 12pcs (radial tires)

Spring few films

13 × 90-10 (optional: -/10/10/10)

King pin

50 # China brand kingpin, opting 90# / JOST.

Landing leg

28T load landing leg, optional JOST.

Braking system

Optional: China brand 4S/2M ABS / WABCO ABS

Optional

Optional container twist locker, and different ramp.

Accessories

Mudguards

PVC Mudguards

Side protection

Nil.

Fire extinguishers carriers

2 pcs

Spare tire carrier

1 pc

Tool box

1 tool box with our factory's standard free tools

3 Axle 100 Ton Low Bed Semi Trailer Heavy Duty Flatbed Trailer With Manual Ramp

3 Axle 100 Ton Low Bed Semi Trailer Heavy Duty Flatbed Trailer With Manual Ramp

3 Axle 100 Ton Low Bed Semi Trailer Heavy Duty Flatbed Trailer With Manual Ramp
