8000L 8M3 HOWO 4 X 2 Garbage Compactor Truck Q235 Carbon Steel Tank
8000L 8M3 HOWO 4 X 2 Garbage Compactor Truck Q235 Carbon Steel Tank
8000L 8M3 HOWO 4 X 2 Garbage Compactor Truck Q235 Carbon Steel Tank
8000L 8M3 HOWO 4 X 2 Garbage Compactor Truck Q235 Carbon Steel Tank
8000L 8M3 HOWO 4 X 2 Garbage Compactor Truck Q235 Carbon Steel Tank
8000L 8M3 HOWO 4 X 2 Garbage Compactor Truck Q235 Carbon Steel Tank
8000L 8M3 HOWO 4 X 2 Garbage Compactor Truck Q235 Carbon Steel Tank
8000L 8M3 HOWO 4 X 2 Garbage Compactor Truck Q235 Carbon Steel Tank
Specifications
Brand Name :
SUNY
Model Number :
CSC5087ZYSZ
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD 25000-30000 / Set
Supply Ability :
50 sets per month
Delivery Time :
25 days after receiving deposits
Packaging Details :
bulk, ro-ro, container
Type :
4 X 2 Garbage Compactor Truck
G. V. W. ( kg ) :
8280
Wheelbase (mm) :
3800
Tire & Quantity :
7.50-16 & 6+1
Engine :
CY4102-CE40
Maximum Power :
83kw/113hp
Dustbin Material :
Q235 Carbon Steel
Dustbin Volume (m3) :
8
Description

4 X 2 HOWO Garbage Truck 8000L 8M3 Garbage Compactor Truck

Product Description:

Compression garbage truck is the urban sanitation special vehicle which is used to highly collecting,transiting garbage and could avoid to leak along the way leading to secondary pollution in the collecting and transiting process.It is the ideal urban sanitation equipment.

1. The collecting method is simple.

2. High compression ratio and big loading capacity

3. Automatic operation: adopting computer controlling system, could set two operating models with full-automation and half-automation.

1. Product Parameter:

Products Technical Specification

Type

4*2 Garbage Compactor Truck

Brand

HOWO

Cab

Single row

Vehicle Description

Overall dimensions (mm)

7200 * 2280 * 2680

G.V.W (kg)

8280

Curb weight(vehicle) (kg)

6205

Loading capacity (kg)

5000-8000

Max speed (Km/h)

95

Engine Description

Engine model

CY4102-CE40

Maximum power

83kw / 113hp

Displacement (lit)

3856

Chassis Description

Chassis Model

CSC5087ZYSZ

Wheel base (mm)

3800

F / R track base (mm)

1750 / 1640

F / R overhang (mm)

1180 / 2170

Approach/Departure angle (°)

20 / 10

Spring plate

11 / 9+7

Front axle / rear axle load capacity (t)

2.2 / 5

Type of fuel

Diesel

Gear box

5-speed with over drive

Brake system

Air braking

Operation control system

Power steering wheel

Electric system

24V

Tires&Tire quantity

7.50-16 & 6+1

Compactor Description

Effective dustbin volume (m3)

8

Dustbin material

Q235 Carbon Steel

Thickness (mm)

Side plate:4mm;Bottom plate:5mm

Precompressor capacity (m3)

1

Rated pressure of hydraulic system (Mpa)

16

The loading device mouth height from the ground (mm)

900

Precompressor working period (s)

6-8

Precompressor lifting period(s)

15

Pushing the board to unloading garbage period (s)

30

Pushing board from

Hydraulic

Effluent tank capacity (L)

8

Dustbin tank capacity (L)

250

Hydraulic oil tank capacity (L)

80
8000L 8M3 HOWO 4 X 2 Garbage Compactor Truck Q235 Carbon Steel Tank
2. Packing and Shipping:

Truck is nude packing, shipping in container, in bulk , in ro-ro.

We will choose the best shipping type basis on truck volume, truck structure, Sail Schedule, clients’ requirement for clients!

3. Company Information:

Hubei Suny Automobile And Machinery Co., Ltd is a professional company who deal in different kinds of special vehicles, trailers and construction machinery.

Our advantage:

(1) We have own factory located in Suizhou---the special truck town of China.We can control every details----the development, the quality and the cost. As a result we can supply the quality goods with most competitve price.

(2) We are familiar with the whole Chinese special truck market. And we are clear the different advantage and different quality level for each factory. So we can consolidate the resource for the customers and supply the most suitable goods for them.

(3) There is a stronge professional team in our company including engineers and business executives. So we can provide the best solution and service for all customers.

If you have any other questions or there is anything we can do for you, pls feel freely to let me know. We are glad to provide the best service.

4. Our Service:

Left-hand drive, if you need Right-hand drives, please inform us, we will make special order for you.

We highly recommend this garbage compactor truck. It's in an excellent condition and also with good quality and competitive price. Further information, pls feel free to cantact with me or visit our website, we will offer our best service.

If you have any requirements about special trucks, kindly let me know, I will do my best fo provide the most suitable type and competetive price for you.

Looking forward to receiving your inquiry!
