8x4 40m3 315HP Oil Tanker Truck Oil Tank Trailer Fonton Auman
8x4 40m3 315HP Oil Tanker Truck Oil Tank Trailer Fonton Auman
8x4 40m3 315HP Oil Tanker Truck Oil Tank Trailer Fonton Auman
8x4 40m3 315HP Oil Tanker Truck Oil Tank Trailer Fonton Auman
8x4 40m3 315HP Oil Tanker Truck Oil Tank Trailer Fonton Auman
8x4 40m3 315HP Oil Tanker Truck Oil Tank Trailer Fonton Auman
8x4 40m3 315HP Oil Tanker Truck Oil Tank Trailer Fonton Auman
8x4 40m3 315HP Oil Tanker Truck Oil Tank Trailer Fonton Auman
8x4 40m3 315HP Oil Tanker Truck Oil Tank Trailer Fonton Auman
8x4 40m3 315HP Oil Tanker Truck Oil Tank Trailer Fonton Auman
8x4 40m3 315HP Oil Tanker Truck Oil Tank Trailer Fonton Auman
8x4 40m3 315HP Oil Tanker Truck Oil Tank Trailer Fonton Auman
Specifications
Brand Name :
SUNY
Model Number :
PJQ5317GYY
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Supply Ability :
1000 units/per year
Delivery Time :
25~35 days after we get the deposit
Packaging Details :
Ro-ro sihpping / Bulk cargo shipping / Container shipping / SKD / CKD / etc
Price :
USD 25,800~ 50,000 FOB Shanghai
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Chassis model :
BJ5317GYY-XB
Cab :
One and half row
Emission standard :
Euro 4
Engine model :
ISLe315 40
Tank volume :
40 m3
Horsepower :
315 HP
Description

Fonton Auman 315 HP Tank Truck 40 m3 Oil Tanker 8x4 Fuel Tank Truck

Description & Applications:

1. Tank is made of carbon steel .the whole tank can be separated into several unattached parts. Diaphragm is welded in the middle of tank to reduce the pressure during the transportation.
2. Antirust paint is pained and container indicator is installed to show the capacity of the tank during the pump in or out.
3. In order to ensure the tank pressure and atmospheric pressure are basically the same during their working, breathing valve is installed in the covered pot CUHK. When the tank pressure is higher than the outside pressure 8KPa, the front breathing valve would open; When the tank pressure is lower than the outside pressure 3KPa, the real breathing valve would open.

4. Tank material:Carbon steel,stainless.rubber and plastic inside,plastic tank,aluminium tank.
5. Loading medium:Crude oil,petroleum/diesel,eatable oil,water,alcohol etc.
6. Independent compartments,loading different oil,chemical oil or eatable oil.
7. Function option: pump in and pump out through flow meter,pump in and pump out not through flow meter,not through meter etc.

Fonton Auman 315 HP Tank Truck 40 m3 Oil Tanker 8x4 Fuel Tank Truck

Vehicle Description

Vehicle model

PJQ5317GYY

Vehicle type

Oil tank truck

Drive form

8x4

Overall dimension (mm)

11915x2495x3440

G.V.W (kg)

41000

Load capacity (kg)

28000

Curb weight (kg)

12305

Chassis Description

Chassis model

BJ5317GYY-XB

Axle load (kg)

6056 / 6944 / 18000 (two axis)

F/R overhang (mm)

1555 / 2500,

1555 / 2450,

1532 / 2470,

1532 / 2445

Approach/Departure angle (°)

13 / 11

Tread(mm)

2010, 1940 / 1847, 1860

Wheelbase(mm)

1800+4700+1350

Spring plate

13 / 14 / 12, 10 / 10 / 10

Tyre size & quantity

11.00R20, 11R22.5

Cab

One and half row

Engine Description

Engine model

ISLe315 40

Displacement (ml)

3900

Max power (kw)

231.5

Horsepower (hp)

315

Max speed (km/h)

79

Emission standard

Euro 4

Type of fuel

Diesel

Tank Description

Tank volume (m³)

40

Tank size (mm)

9200x2450x1820
