Chemical Liquid International Tank Trailer Double Full Axle 15000L
Chemical Liquid International Tank Trailer Double Full Axle 15000L
Chemical Liquid International Tank Trailer Double Full Axle 15000L
Chemical Liquid International Tank Trailer Double Full Axle 15000L
Chemical Liquid International Tank Trailer Double Full Axle 15000L
Chemical Liquid International Tank Trailer Double Full Axle 15000L
Chemical Liquid International Tank Trailer Double Full Axle 15000L
Chemical Liquid International Tank Trailer Double Full Axle 15000L
Specifications
Brand Name :
SUNY
Model Number :
SY9215FGYY
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD 14,800~ 22,000 FOB Shanghai
Payment Terms :
T/T, L/C, Western Union, Paypal, MoneyGram,
Supply Ability :
1000 units/per year
Delivery Time :
25~35 days after we get the deposit
Packaging Details :
Ro-ro sihpping / Bulk cargo shipping / Container shipping / SKD / CKD / etc
Fuel Tank capacity :
15000 L
Fuel Tank material :
Mild steel Q345 / Q235
Working pressure :
0.9 bar
Whole trailer dimension :
4800*2500*3500 mm
Fuel tank trailer :
2 axle FUWA mechanical suspension
Loading system :
Mechanical or Pneumatic
Fuel tank color :
opting
Fuel Tank shape :
Trapezoid shape
Description

15000 L Oil Tanker Trailer 2 Axle Oil Tanker Tractor Full Trailer

Description & Applications:

Oil tank semi trailer and full trailer is tractor head connecting oil tank trailer or dogging full trailer. Compared with the ordinary single type tank car, semi-trailer tanker carrying oil can effectively improve the transportation efficiency. In the case of the same tonnage, reduce transportation costs, save fuel consumption.

Oil tank trailer in the rear of the tractor is approximately the similar, ordinary more are double (two axles), or bridge (tri-axle) points, according to the need to choose the traction head. And we can fabricate different axle and tires models in according to customer’s requirement.

We also produce all kinds of aluminum oil tank trailer with various international standards, and stainless steel oil tank semi trailer, mild steel tanker semi trailer.

Competitive Advantage:
We can be completely customized all different truck and trailer according to customer needs; with advanced design concept; the production process and the first class process, as well as services; competitive prices.


Specifications:


15000 L oil tank full trailer 2 axle

Model : SY9215FGYY (15000 L fuel tanker trailer 2 axle oil tank full trailer)

DIMENSIONS & WEIGHT

Overall Dimensions (L*W*H)

4800*2500*3500 mm (reference dimensions)

Volume

15000 Liters = 15 m3

MAX. GVW

Approx 2000 kg

Kerb weight

Approx ≤ 5000 kg

Rated payload

Approx 15000 kg

TANKER

Main tank shell ( material / thickness )

Mild steel Q345 ( 4 mm ), opting aluminum

Head, Wash plate ( material / thickness )

Mild steel Q345 ( 5 mm ), opting aluminum

Tanker bottom beam

( material / thickness )

Full loading straight type, opting aluminum

Top coaming ( material / thickness )

Mild steel, opting aluminum

Overturn protection

( material / thickness )

Mild steel, opting aluminum

Tank shape

Trapezoid shape

Compartments

1 compartments, opting more compartments.

TANK TOP ACCESSORIES

Aluminum Ladder with pneumatic control aluminum handrail in rear up to the tank top walkway.
With AL Anti-slip Walkway on the top.

TANK EQUIPMENT

Manhole

Opting different brand

Foot valve

Opting different brand

API standard quick connector - drain valve

Opting different brand

API adjustable joints

Opting different brand

API connector dust cover

Opting different brand

Vapor recovery system

Opting different brand

Pneumatic control system

Opting different brand

Discharge method

Gravity discharge

RUNNING GEAR

Axle

FUWA 2 * 13 T axles, double wheel,
opting BPW axle and single wheel type.

Suspension

Mechanical, opting pneumatic.

Tire and Rim

8+1 tires 11.00R22.5
8+1 pcs steel rims, opting aluminum rims

King pin

Dog trailer hanging pin

Rear Bumper

1 set LTA approval rear heavy duty under-run bumper

BRAKING SYSTEM

Double line air brakes Mechanical parking brake with WABCO emergency relay valve. Air braking.
WABCO ABS SYSTEM 4S/2M

ELECTRIC INSTALLATION

Complete 24V system in explosion proof installation. 7 pin socket for tractor connection. With Junction box
LED lights. Rear lighting with rear, stop, parking, direction, fog, reverse lights, side lights
With the reverse buzzer

PAINTING

Factory standard painting system. Color and logo optional.

ACCESSORIES

Mudguards

PVC Mudguards for each tire.

Drain hose

√

Earthing strip

√

Fire extinguishers carriers

√

Spare tire carrier

√

Tool box

√
