5000 L Water Sprinkle Fire Fighting Vehicle Dongfeng Chassis 4*2 Drive
5000 L Water Sprinkle Fire Fighting Vehicle Dongfeng Chassis 4*2 Drive
5000 L Water Sprinkle Fire Fighting Vehicle Dongfeng Chassis 4*2 Drive
5000 L Water Sprinkle Fire Fighting Vehicle Dongfeng Chassis 4*2 Drive
5000 L Water Sprinkle Fire Fighting Vehicle Dongfeng Chassis 4*2 Drive
5000 L Water Sprinkle Fire Fighting Vehicle Dongfeng Chassis 4*2 Drive
Specifications
Brand Name :
SUNY
Model Number :
SY5102XFSH
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD22000 /set- USD45000/set
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
200 set per month
Delivery Time :
15-25 working days
Packaging Details :
Ro-ro sihpping / Bulk cargo shipping / Container shipping / SKD / CKD / etc
Chassis brand/ model :
Dongfeng/ EQ1070TJ9AD3
Water tank capacity :
5000 L
Function :
Water sprinkle and rescue
Dimension :
7000 x 2300 x 2500 mm
Drive :
4X2
Wheel base :
3800 mm
Engine :
CY4102-E3C
G.V. W :
7200 kgs
Tank material :
Q235
Axles No. :
2
Description

5000 L Water Sprinkle Fire Fighting Trucks Dongfeng Chassis 4*2 Drive

Description & application:

Multifunction fire sprinkler truck , compared with normal fire truck, although the lack of equipment boxes,but with the same range of fire engines, has the same function with fire truck.
Compared with the water sprinkler truck, inherits all the features of water sprinkler truck, but also to make up for the water sprinkler truck range is small, pressure and other issues.
Also can be used in dry areas of water transport truck.


Competitive Advantage:


1- powful R & D capabilities ---- we can design and produce the truck according to different fire equipment of different countries so that it can be fit for different countries’ demand.
2- strict quality control ---- stable quality for each truck
3- competitive price ----- based on same product, our price is most competitive
4- best service ----- we cherish each customer and opportunity.

Specifications:

5000 L water sprinkle fire fighting truck dongfeng chassis 4*2 drive

Main specification

Product model and name

Dongfeng 5000l Fire fighting truck

Overall dimension(mm)

7000 x 2300 x 2500mm

Chassis model

EQ1070TJ9AD3

Chassis Brand

Dongfeng

Wheelbase(mm)

3800

Max speed(Km/h)

80

Tyre specification

7.50-16

Tyre No.

6+1(spare tyre)

Emission standard

Euro III

Transmission

5 forward gear,

1 reverse gear

Engine model

Engine manufacturer

Displacement(ml)

Power(Kw)

CY4102-E3C

Dongfeng Chaoyang Diesel Co.,Ltd

3856

91

Water tank fire fighting truck performance

Water tank volume(L)

5000

Fire monitor

Fire monitor model PS30, Range≥50 m/1.0MPa

Fire pump

Model:CB10/30

Spare parts

1.Suction pipe: 2 pcs 2.Wrench: 2 pcs 3.Operation manual 4. Basic hand tool 5.Spare tyre

Remarks: This quotation is not include equipment box and fire equipment.
